@ -127,4 +127,8 @@ This is the stream throughput in MB/s and is usually about 3 times the sample ra
<h3>19: FIFO status</h3>
This is the fill percentage of the Tx FIFO in the LimeSuite interface. In normal conditions this should be ~100%. On the picture the Tx is not started.
This is the fill percentage of the Tx FIFO in the LimeSuite interface. In normal conditions this should be ~100%. On the picture the Tx is not started.
<h3>20: Board temperature</h3>
This is the board temperature in degrees Celsius updated every ~5s. Before the first probe the display marks "00C" this is normal.

6
plugins/samplesource/limesdrinput/readme.md
View File

@ -145,4 +145,8 @@ This is the stream throughput in MB/s and is usually about 3 times the sample ra
<h3>19: FIFO status</h3>
This is the fill percentage of the Rx FIFO in the LimeSuite interface. It should be zero most of the time.
This is the fill percentage of the Rx FIFO in the LimeSuite interface. It should be zero most of the time.
<h3>20: Board temperature</h3>
This is the board temperature in degrees Celsius updated every ~5s. Before the first probe the display marks "00C" this is normal.
