Merge branch 'support-2.3.1' into release-2.4.0

Decoder/decodedtext.cpp

@@ -16,11 +16,15 @@ namespace

 DecodedText::DecodedText (QString const& the_string)
   : string_ {the_string.left (the_string.indexOf (QChar::Nbsp))} // discard appended info
+  , clean_string_ {string_}
   , padding_ {string_.indexOf (" ") > 4 ? 2 : 0} // allow for
                                                     // seconds
   , message_ {string_.mid (column_qsoText + padding_).trimmed ()}
   , is_standard_ {false}
 {
+  // discard appended AP info
+  clean_string_.replace (QRegularExpression {R"(^(.*)(?:(?:\?\s)?a[0-9].*)$)"}, "\\1");
+
 //  qDebug () << "DecodedText: the_string:" << the_string << "Nbsp pos:" << the_string.indexOf (QChar::Nbsp);
   if (message_.length() >= 1)
     {

Decoder/decodedtext.h

@@ -32,6 +32,7 @@ public:
   explicit DecodedText (QString const& message);

   QString string() const { return string_; };
+  QString clean_string() const { return clean_string_; };
   QStringList messageWords () const;
   int indexOf(QString s) const { return string_.indexOf(s); };
   int indexOf(QString s, int i) const { return string_.indexOf(s,i); };
@@ -76,6 +77,7 @@ private:
       column_qsoText = 22 };

   QString string_;
+  QString clean_string_;
   int padding_;
   QString message_;
   QString message0_;

MultiSettings.cpp

@@ -576,20 +576,28 @@ void MultiSettings::impl::select_configuration (QString const& target_name)
 {
   if (main_window_ && target_name != current_)
     {
+      bool changed {false};
       {
         auto const& current_group = settings_.group ();
         if (current_group.size ()) settings_.endGroup ();
         // position to the alternative settings
         SettingsGroup alternatives {&settings_, multi_settings_root_group};
-        // save the target settings
-        SettingsGroup target_group {&settings_, target_name};
-        new_settings_ = get_settings ();
+        if (settings_.childGroups ().contains (target_name))
+          {
+            changed = true;
+            // save the target settings
+            SettingsGroup target_group {&settings_, target_name};
+            new_settings_ = get_settings ();
+          }
         if (current_group.size ()) settings_.beginGroup (current_group);
       }
-      // and set up the restart
-      current_ = target_name;
-      Q_EMIT parent_->configurationNameChanged (unescape_ampersands (current_));
-      restart (RepositionType::save_and_replace);
+      if (changed)
+        {
+          // and set up the restart
+          current_ = target_name;
+          Q_EMIT parent_->configurationNameChanged (unescape_ampersands (current_));
+          restart (RepositionType::save_and_replace);
+        }
     }
 }


SampleDownloader.cpp

@@ -117,7 +117,7 @@ SampleDownloader::impl::impl (QSettings * settings
   main_layout_.addLayout (&left_layout_, 0, 0);
   main_layout_.addWidget (&button_box_, 0, 1);
   main_layout_.addWidget (&details_widget_, 1, 0, 1, 2);
-  main_layout_.setRowStretch (1, 2);
+  main_layout_.setRowStretch (0, 2);
   setLayout (&main_layout_);

   connect (&button_box_, &QDialogButtonBox::clicked, this, &SampleDownloader::impl::button_clicked);

SampleDownloader/Directory.cpp

@@ -49,6 +49,8 @@ Directory::Directory (Configuration const * configuration

   setColumnCount (2);
   setHeaderLabels ({tr ("File"), tr ("Progress")});
+  headerItem ()->setTextAlignment (0, Qt::AlignHCenter);
+  headerItem ()->setTextAlignment (1, Qt::AlignHCenter);
   header ()->setSectionResizeMode (QHeaderView::ResizeToContents);
   setItemDelegate (&item_delegate_);

@@ -294,14 +296,15 @@ void Directory::update (QTreeWidgetItem * item)
       int counted {0};

       // get the count, progress and size of children
-      int items {recurse_children (item, &counted, &bytes, &max)};
+      // int items {recurse_children (item, &counted, &bytes, &max)};
+      recurse_children (item, &counted, &bytes, &max);

       // estimate size of items not yet downloaded as average of
       // those actually present
-      if (counted)
-        {
-          max += (items - counted) * max / counted;
-        }
+      // if (counted)
+      //   {
+      //     max += (items - counted) * max / counted;
+      //   }

       // save as our progress
       item->setData (1, Qt::UserRole, max);

SampleDownloader/DirectoryDelegate.cpp

@@ -14,28 +14,42 @@ void DirectoryDelegate::paint (QPainter * painter, QStyleOptionViewItem const& o
 {
   if (1 == index.column ())
     {
-      QStyleOptionProgressBar progress_bar_option;
-      progress_bar_option.rect = option.rect;
-      progress_bar_option.state = QStyle::State_Enabled;
-      progress_bar_option.direction = QApplication::layoutDirection ();
-      progress_bar_option.fontMetrics = QApplication::fontMetrics ();
-      progress_bar_option.minimum = 0;
-      progress_bar_option.maximum = 100;
       auto progress = index.data ().toLongLong ();
+      qint64 percent;
       if (progress > 0)
         {
-          auto percent = int (progress * 100 / index.data (Qt::UserRole).toLongLong ());
-          progress_bar_option.progress = percent;
-          progress_bar_option.text = QString::number (percent) + '%';
-          progress_bar_option.textVisible = true;
-          progress_bar_option.textAlignment = Qt::AlignCenter;
+          percent = int (progress * 100 / index.data (Qt::UserRole).toLongLong ());
+        }
+#if !defined (Q_OS_DARWIN)
+      QStyleOptionProgressBar progress_option;
+      auto control_element = QStyle::CE_ProgressBar;
+      progress_option.minimum = 0;
+      progress_option.maximum = 100;
+      progress_option.textAlignment = Qt::AlignCenter;
+      if (progress > 0)
+        {
+          progress_option.progress = percent;
+          progress_option.textVisible = true;
         }
       else
         {
           // not started
-          progress_bar_option.progress = -1;
+          progress_option.progress = -1;
         }
-      QApplication::style ()->drawControl (QStyle::CE_ProgressBar, &progress_bar_option, painter);
+#else
+      // workaround for broken QProgressBar item delegates on macOS
+      QStyleOptionViewItem progress_option;
+      auto control_element = QStyle::CE_ItemViewItem;
+      progress_option.displayAlignment = Qt::AlignHCenter;
+      progress_option.index = index;
+      progress_option.features = QStyleOptionViewItem::HasDisplay;
+#endif
+      progress_option.rect = option.rect;
+      progress_option.state = QStyle::State_Enabled;
+      progress_option.direction = QApplication::layoutDirection ();
+      progress_option.fontMetrics = QApplication::fontMetrics ();
+      progress_option.text = QString::number (progress > 0 ? percent : 0) + '%';
+      QApplication::style ()->drawControl (control_element, &progress_option, painter);
     }
   else
     {

SampleDownloader/FileNode.cpp

@@ -27,7 +27,12 @@ FileNode::FileNode (QTreeWidgetItem * parent

 void FileNode::error (QString const& title, QString const& message)
 {
-  MessageBox::warning_message (treeWidget (), title, message);
+  if (MessageBox::Retry == MessageBox::warning_message (treeWidget (), title, message
+                                                        , QString {}, MessageBox::Cancel | MessageBox::Retry
+                                                        , MessageBox::Cancel))
+    {
+      sync (true);
+    }
 }

 bool FileNode::sync (bool local)

Transceiver/HamlibTransceiver.cpp

@@ -436,7 +436,11 @@ HamlibTransceiver::HamlibTransceiver (logger_type * logger,
         {
           m_->set_conf ("ptt_type", "RTS");
         }
+      set_conf ("ptt_share", "1");
     }
+
+  // do this late to allow any configuration option to be overriden
+  load_user_settings ();
 }

 HamlibTransceiver::HamlibTransceiver (logger_type * logger,
@@ -453,52 +457,7 @@ HamlibTransceiver::HamlibTransceiver (logger_type * logger,

   // m_->rig_->state.obj = this;

-  //
-  // user defined Hamlib settings
-  //
-  auto settings_file_name = QStandardPaths::locate (QStandardPaths::AppConfigLocation
-                                                    , "hamlib_settings.json");
-  if (!settings_file_name.isEmpty ())
-    {
-      QFile settings_file {settings_file_name};
-      qDebug () << "Using Hamlib settings file:" << settings_file_name;
-      if (settings_file.open (QFile::ReadOnly))
-        {
-          QJsonParseError status;
-          auto settings_doc = QJsonDocument::fromJson (settings_file.readAll (), &status);
-          if (status.error)
-            {
-              throw error {tr ("Hamlib settings file error: %1 at character offset %2")
-                             .arg (status.errorString ()).arg (status.offset)};
-            }
-          qDebug () << "Hamlib settings JSON:" << settings_doc.toJson ();
-          if (!settings_doc.isObject ())
-            {
-              throw error {tr ("Hamlib settings file error: top level must be a JSON object")};
-            }
-          auto const& settings = settings_doc.object ();
-
-          //
-          // configuration settings
-          //
-          auto const& config = settings["config"];
-          if (!config.isUndefined ())
-            {
-              if (!config.isObject ())
-                {
-                  throw error {tr ("Hamlib settings file error: config must be a JSON object")};
-                }
-              auto const& config_list = config.toObject ();
-              for (auto item = config_list.constBegin (); item != config_list.constEnd (); ++item)
-                {
-                  m_->set_conf (item.key ().toLocal8Bit ().constData ()
-                                , (*item).toVariant ().toString ().toLocal8Bit ().constData ());
-                }
-            }
-        }
-    }
-
-  if (!m_->is_dummy_)
+  if (!is_dummy_)
     {
       switch (rig_get_caps_int (m_->model_, RIG_CAPS_PORT_TYPE))
         {
@@ -592,17 +551,69 @@ HamlibTransceiver::HamlibTransceiver (logger_type * logger,
         {
           m_->set_conf ("ptt_type", "RTS");
         }
+      set_conf ("ptt_share", "1");
     }

   // Make Icom CAT split commands less glitchy
   m_->set_conf ("no_xchg", "1");

+  // do this late to allow any configuration option to be overriden
+  load_user_settings ();
+
   // would be nice to get events but not supported on Windows and also not on a lot of rigs
   // rig_set_freq_callback (m_->rig_.data (), &frequency_change_callback, this);
 }

 HamlibTransceiver::~HamlibTransceiver () = default;

+void HamlibTransceiver::load_user_settings ()
+{
+  //
+  // user defined Hamlib settings
+  //
+  auto settings_file_name = QStandardPaths::locate (QStandardPaths::AppConfigLocation
+                                                    , "hamlib_settings.json");
+  if (!settings_file_name.isEmpty ())
+    {
+      QFile settings_file {settings_file_name};
+      qDebug () << "Using Hamlib settings file:" << settings_file_name;
+      if (settings_file.open (QFile::ReadOnly))
+        {
+          QJsonParseError status;
+          auto settings_doc = QJsonDocument::fromJson (settings_file.readAll (), &status);
+          if (status.error)
+            {
+              throw error {tr ("Hamlib settings file error: %1 at character offset %2")
+                             .arg (status.errorString ()).arg (status.offset)};
+            }
+          qDebug () << "Hamlib settings JSON:" << settings_doc.toJson ();
+          if (!settings_doc.isObject ())
+            {
+              throw error {tr ("Hamlib settings file error: top level must be a JSON object")};
+            }
+          auto const& settings = settings_doc.object ();
+
+          //
+          // configuration settings
+          //
+          auto const& config = settings["config"];
+          if (!config.isUndefined ())
+            {
+              if (!config.isObject ())
+                {
+                  throw error {tr ("Hamlib settings file error: config must be a JSON object")};
+                }
+              auto const& config_list = config.toObject ();
+              for (auto item = config_list.constBegin (); item != config_list.constEnd (); ++item)
+                {
+                  set_conf (item.key ().toLocal8Bit ().constData ()
+                            , (*item).toVariant ().toString ().toLocal8Bit ().constData ());
+                }
+            }
+        }
+    }
+}
+
 int HamlibTransceiver::do_start ()
 {
   CAT_TRACE ("starting: " << rig_get_caps_cptr (m_->model_, RIG_CAPS_MFG_NAME_CPTR)

Transceiver/HamlibTransceiver.hpp

@@ -24,6 +24,7 @@ public:
   ~HamlibTransceiver ();

 private:
+  void load_user_settings ();
   int do_start () override;
   void do_stop () override;
   void do_frequency (Frequency, MODE, bool no_ignore) override;

WSJTXLogging.cpp

@@ -192,7 +192,7 @@ WSJTXLogging::WSJTXLogging ()
         (
          sinks::file::make_collector
          (
-          keywords::max_size = 40 * 1024 * 1024
+          keywords::max_size = 5 * 1024 * 1024
           , keywords::min_free_space = 1024 * 1024 * 1024
           , keywords::max_files = 12
           , keywords::target = app_data.absoluteFilePath ("logs").toStdWString ()

doc/CMakeLists.txt

@@ -166,9 +166,9 @@ function (document)
       COMMAND ${ASCIIDOCTOR_EXECUTABLE} ${_args_ASCIIDOCTOR_OPTIONS}
       -b html5
       -a nofooter
-      -a VERSION_MAJOR=${WSJTX_VERSION_MAJOR}
-      -a VERSION_MINOR=${WSJTX_VERSION_MINOR}
-      -a VERSION_PATCH=${WSJTX_VERSION_PATCH}
+      -a VERSION_MAJOR=${PROJECT_VERSION_MAJOR}
+      -a VERSION_MINOR=${PROJECT_VERSION_MINOR}
+      -a VERSION_PATCH=${PROJECT_VERSION_PATCH}
       -a VERSION=${wsjtx_VERSION}
       --out-file=${_html_file} ${_source_name}
       DEPENDS ${_args_DEPENDS}
@@ -195,9 +195,9 @@ function (document)
       COMMAND ${ASCIIDOCTOR_EXECUTABLE} ARGS ${_args_ASCIIDOCTOR_OPTIONS}
       -b docbook
       -a data-uri!
-      -a VERSION_MAJOR=${WSJTX_VERSION_MAJOR}
-      -a VERSION_MINOR=${WSJTX_VERSION_MINOR}
-      -a VERSION_PATCH=${WSJTX_VERSION_PATCH}${BUILD_TYPE_REVISION}
+      -a VERSION_MAJOR=${wsjtx_VERSION_MAJOR}
+      -a VERSION_MINOR=${wsjtx_VERSION_MINOR}
+      -a VERSION_PATCH=${wsjtx_VERSION_PATCH}${BUILD_TYPE_REVISION}
       -a VERSION=${wsjtx_VERSION}
       -D ${CMAKE_CURRENT_BINARY_DIR}
       -o ${_docbook_file} ${_source_name}

doc/common/links.adoc

@@ -94,8 +94,8 @@ d). Edit lines as needed. Keeping them in alphabetic order help see dupes.
 :sourceforge-jtsdk: https://sourceforge.net/projects/jtsdk[SourceForge JTSDK]
 :ubuntu_sdk: https://launchpad.net/~ubuntu-sdk-team/+archive/ppa[Ubuntu SDK Notice]
 :win_openssl_packages: https://slproweb.com/products/Win32OpenSSL.html[Windows OpenSSL Packages]
-:win32_openssl: https://slproweb.com/download/Win32OpenSSL_Light-1_1_1h.msi[Win32 OpenSSL Light Package]
-:win64_openssl: https://slproweb.com/download/Win64OpenSSL_Light-1_1_1h.msi[Win64 OpenSSL Light Package]
+:win32_openssl: https://slproweb.com/download/Win32OpenSSL_Light-1_1_1j.msi[Win32 OpenSSL Light Package]
+:win64_openssl: https://slproweb.com/download/Win64OpenSSL_Light-1_1_1j.msi[Win64 OpenSSL Light Package]
 :writelog: https://writelog.com/[Writelog]
 :wsjtx_group:  https://groups.io/g/WSJTX[WSJTX Group]
 :wsjtx: https://physics.princeton.edu/pulsar/K1JT/wsjtx.html[WSJT-X]

doc/user_guide/en/controls-functions-menus.adoc

@@ -37,6 +37,12 @@ examples for configurations `FT8` and `Echo`:
 ==== View Menu
 image::view-menu.png[align="left",alt="View Menu"]

+The *SWL Mode* action reduces the _WSJT-X_ main window to a minimum
+size with just the menus, decodes windows, and status bar visible. You
+may find this useful when running multiple instances of the
+application. Both size and location of the main window are saved and
+recalled independently for this view.
+
 [[MODE_MENU]]
 ==== Mode Menu
 image::mode-menu.png[align="left",alt="Mode Menu"]

doc/user_guide/en/controls-functions-messages.adoc

@@ -1,11 +1,10 @@
 // Status=edited

-Two arrangements of controls are provided for generating and selecting
-Tx messages.  Controls familiar to users of program _WSJT_
-appear on *Tab 1*, providing six fields for message entry.
-Pre-formatted messages for the standard minimal QSO are generated when
-you click *Generate Std Msgs* or double-click on an appropriate line
-in one of the decoded text windows.
+Controls familiar to users of program _WSJT_ appear on *Tab 1*,
+providing six fields for message entry.  Pre-formatted messages for
+the standard minimal QSO are generated when you click *Generate Std
+Msgs* or double-click on an appropriate line in one of the decoded
+text windows.

 //.Traditional Message Menu
 image::traditional-msg-box.png[align="center",alt="Traditional Message Menu"]
@@ -28,31 +27,12 @@ stored messages entered on the *Files -> Settings -> Tx Macros* tab.
 Pressing *Enter* on a modified message #5 automatically adds that
 message to the stored macros.

-* In some circumstances it may be desirable to make your QSOs as
-short as possible.  To configure the program to start contacts with
-message #2, disable message #1 by double-clicking its radio-button in the *Next* column or *Tx 1* button in the *Now* column.  Similarly, to send RR73
-rather than RRR for message #4, double-click one of its buttons.
-
-The second arrangement of controls for generating and selecting
-Tx messages appears on *Tab 2* of the Message Control Panel:
-
-//.New Message Menu
-image::new-msg-box.png[align="center",alt="New Message Menu"]
-
-With this setup you normally follow a top-to-bottom sequence of
-transmissions from the left column if you are calling CQ, or the right
-column if answering a CQ.
-
-* Clicking a button puts the appropriate message in the *Gen Msg* box.
-If you are already transmitting, the Tx message is changed
-immediately.
-
-* You can enter and transmit anything (up to 13 characters, including
-spaces) in the *Free Msg* box.
-
-* Click the pull-down arrow in the *Free Msg* box to select a
-stored macro.  Pressing *Enter* on a modified message here
-automatically adds that message to the table of stored macros.
+* In some circumstances it may be desirable to make your QSOs as short
+as possible.  To configure the program to start contacts with message
+#2, disable message #1 by double-clicking its radio-button in the
+*Next* column or *Tx 1* button in the *Now* column.  Similarly, to
+send RR73 rather than RRR for message #4, double-click one of its
+buttons.

 +


doc/user_guide/en/decoder_notes.adoc

@@ -2,12 +2,12 @@

 === AP Decoding

-The _WSJT-X_ decoders for FT4, FT8, JT65, QRA64, include
+The _WSJT-X_ decoders for FST4, FT4, FT8, JT65, and QRA64 include
 procedures that use naturally accumulating information during a
 minimal QSO.  This _a priori_ (AP) information increases sensitivity
 of the decoder by up to 4 dB, at the cost of a slightly higher rate of
 false decodes.  AP is optional in FT8, JT65, and QRA64, but is always
-enabled for FT4.
+enabled for FT4 and FST4 when decode depth is Normal or Deep.

 For example: when you decide to answer a CQ, you already know your own
 callsign and that of your potential QSO partner.  The software
@@ -27,7 +27,7 @@ example, `a2` indicates that the successful decode used MyCall as
 hypothetically known information.

 [[FT8_AP_INFO_TABLE]]
-.FT4 and FT8 AP information types
+.FST4, FT4, and FT8 AP information types
 [width="35%",cols="h10,<m20",frame=topbot,options="header"]
 |===============================================
 |aP | Message components
@@ -47,7 +47,9 @@ forwarded to {pskreporter}.

 Table 2 lists the six possible QSO states that are tracked by the
 _WSJT-X_ auto-sequencer, along with the type of AP decoding that would
-be attempted in each state.
+be attempted in each state in FT4 or FT8. The FST4 table (not shown)
+is the same except that it omits the decoding attempts for AP types
+4 and 5 to save time.

 [[FT8_AP_DECODING_TYPES_TABLE]]
 .FT4 and FT8 AP decoding types for each QSO state
@@ -109,13 +111,15 @@ summarized in the following Table:
 [width="50%",cols="h,3*^",frame=topbot,options="header"]
 |===========================================
 |Mode    |Mode character|Sync character|End of line information
+|FST4    | `            |      | ? &#160; aP
 |FT4     | ~            |      | ? &#160; aP
 |FT8     | ~            |      | ? &#160; aP
 |JT4     | $            | *, # | f, fN, dCN
 |JT9     | @            |      |
 |JT65    | #            |      |
 |JT65 VHF| #            | *, # | f, fN, dCN
-|QRA64   | :            | *    | R
+|QRA64   | :            | *    | R:w
+
 |ISCAT   |              | *    | M  N  C  T
 |MSK144  | &            |      |
 |===========================================

doc/user_guide/en/make-qso.adoc

@@ -160,7 +160,7 @@ guidelines for contest logging with FT4, FT8, and MSK144:
 [[COMP-CALL]]
 === Nonstandard Callsigns

-*FT4, FT8, and MSK144*
+*FT4, FT8, FST4, and MSK144*

 Compound callsigns like xx/K1ABC or K1ABC/x and special event
 callsigns like YW18FIFA are supported for normal QSOs but not for

doc/user_guide/en/new_features.adoc

@@ -31,4 +31,9 @@ synchronization symbols.
 for making 2-way QSOs, and FST4W should replace WSPR for propagation
 tests*.  Operating conventions on these LF and MF bands will
 eventually determine the most useful T/R sequence lengths for each
-type of operation.
+type of operation. We also expect that the 60 second variant of FST4
+(FST4-60) will outperform JT9 for DX QSOs on HF bands due, in part,
+to the FST4 decoder's ability to use AP decoding for messages received
+from a QSO partner. In addition, FST4 provides the added benefits
+associated with 77-bit messages and auto-sequencing.
+

doc/user_guide/en/settings-colors.adoc

@@ -18,6 +18,13 @@ image::colors.png[align="center",alt="Colors Screen"]
 * Check *Highlight by Mode* if you wish worked before status to be per
   <<INTRO,mode>>.

+* Check *Only grid Fields sought* if you are only interested in the
+  leading two character grid locator Fields rather than teh four
+  character grid locator Squares.
+
+* Check *Include extra WAE entities* if you are interested in the
+  extra entities defined for DARC WAE and CQ Marathon awards.
+
 * Worked before status is calculated from your _WSJT-X_ ADIF
   <<LOGGING, Logging>> file, you may replace ADIF log file with one
   exported from your station logging application, *Rescan ADIF Log*

doc/user_guide/en/settings-radio.adoc

@@ -96,5 +96,6 @@ green to indicate that proper communication has been established.
 Failure of the CAT-control test turns the button red and displays an
 error message.  After a successful CAT test, toggle the *Test PTT*
 button to confirm that your selected method of T/R control is working
-properly. (If you selected *VOX* for _PTT Method_, you can test T/R
+properly, the button turns red if the rig has been successfully
+keyed. (If you selected *VOX* for _PTT Method_, you can test T/R
 switching later by using the *Tune* button on the main window.)

doc/user_guide/en/settings-reporting.adoc

@@ -19,6 +19,10 @@ QRZ messages. Full details of the protocol can be found in comments
 at the top of this file in our source code repository:
 https://sourceforge.net/p/wsjt/wsjtx/ci/master/tree/Network/NetworkMessage.hpp

+NOTE: The *Outgoing interfaces* and *Multicast TTL* fields are only
+      present when a multicast group IP address has been entered in
+      the *UDP Server* field.
+
 Programs like _JTAlert_ use the _UDP Server_ feature to obtain
 information about running _WSJT-X_ instances.  If you are using
 _JTAlert_ to control _WSJT-X_, be sure to check the

doc/user_guide/en/settings-txmacros.adoc

@@ -16,6 +16,5 @@ characters) in the entry field at top, then click *Add*.
 - You can reorder your macro messages by using drag-and-drop. The
 new order will be preserved when _WSJT-X_ is restarted.

-- Messages can also be added from the main window's *Tx5* field on Tab
-1 or the *Free msg* field on Tab 2. Simply hit [Enter] after the
-message has been entered.
+- Messages can also be added from the main window's *Tx5*
+  field. Simply hit [Enter] after the message has been entered.

doc/user_guide/en/tutorial-example5.adoc

@@ -1,5 +1,19 @@
 Do not confuse FST4 with FT4, which has a very different purpose!
-FST4 is is designed for making 2-way QSOs on the LF and MF bands.
+FST4 is designed primarily for making weak-signal 2-way QSOs on the
+LF and MF bands. T/R periods from 15 s up to 1800 s are
+available. Longer T/R periods provide better sensitivity only if
+Tx and Rx frequency instability and channel Doppler spread
+are small enough so that received signals
+remain phase coherent over periods spanning several transmitted symbols.
+Generally speaking, Rx and Tx frequency changes
+during the transmission and channel Doppler spread should each be small compared
+to the symbol keying rate shown for each T/R duration in Table 7 within section
+<<PROTOCOL_OVERVIEW,Protocol Specifications>>. For example, the keying rate for
+the 1800 s T/R period is 0.089 Baud, so
+successful operation using this T/R length requires Tx and Rx frequency
+stability better than 0.089 Hz over the duration of the 1800 s transmission in
+addition to channel Doppler spread smaller than 0.089 Hz.
+
 Operation with FST4 is similar to that with other _WSJT-X_ modes: most
 on-screen controls, auto-sequencing, and other features behave in
 familiar ways.  However, operating conventions on the 2200 and 630 m
@@ -21,3 +35,26 @@ decoding process (and of course will be undecodable).  By checking
 further limit the decoding range to the setting of *F Tol* on
 either side of *Rx Freq*.

+A noise blanker can be enabled by setting the *NB* percentage to a non-zero value.
+This setting determines how many of the largest-amplitude samples will be
+blanked (zeroed) before the data is submitted to the decoder. Most users find
+that settings between 0% (no blanking) and 10% work best. If the noise
+blanker percentage is set to -1%, then the decoder will try 0, 5, 10, 15, and 20 %
+in succession. Similarly, a setting of -2% causes the decoder to loop over
+blanking percentages 0, 2, 4, ... 20 %. To save time, the multiple blanking
+percentages triggered by negative *NB* settings are tried only for signal
+candidates located near (within +/- 20 Hz) of the *Rx* frequency setting.
+
+.Open a sample Wave File:
+
+- Select *FST4* on the *Mode* menu. Set *T/R* to 60 s and *Decode | Deep*.
+- Set *NB* (noise blanker) to 0%.
+- Set up the Wide Graph display with settings appropriate for the FST4-60 mode.
+For example, try *Bins/Pixel* 2 and *N Avg* 4. Set the *Start* frequency and the width of
+the Wide Graph to include the frequency range that you want to decode. For this
+example, make sure that *Start* is less than 1000 Hz and that the Wide Graph extends to above 1400 Hz.
+- Set *F Low* 1000, *F High* 1400. These settings define the decoder's frequency search range.
+- Open a sample Wave file using *File | Open* and select the file
+...\save\samples\FST4+FST4W\210115_0058.wav. After _WSJT-X_ has processed the file you should see something similar to the following screen shot:
+
+image::FST4-1.png[align="left"]

doc/user_guide/en/tutorial-example6.adoc

@@ -1,5 +1,5 @@
 FST4W is used in the same way as WSPR, but FST4W has significant
-advantages for use on the 2200 and 630 m bands.  By default the
+advantages for use on the 2200 m and 630 m bands.  By default the
 central *Rx Freq* is 1500 Hz and *F Tol* is 100 Hz, so the active
 decoding range is 1400 to 1600 Hz.  However, for added flexibility you
 can select different center frequencies and *F Tol* values.  We expect
@@ -16,3 +16,19 @@ If three operators agree in advance to select the options *1/3*,
 a fixed sequence with no two stations transmitting simultaneously.
 Sequence 1 is the first sequence after 00:00 UTC.  For WSPR-like
 scheduling behavior, you should select *Random* with this control.
+
+.Open a Wave File:
+
+- Select *FST4W* on the *Mode* menu. Set *T/R* to 1800 s and *Decode | Deep*.
+- Set *NB* to 0%.
+- Select appropriate wide graph settings. For example, try *Bins/Pixel* 1,
+*Start* 1200 Hz and *N Avg* 150.
+- Open a sample Wave file using *File | Open* and select the file
+...\save\samples\FST4+FST4W\201230_0300.wav.
+When it is finished you should see a single decode as shown in the
+screenshot:
+
+image::FST4W-1.png[align="left"]
+
+Note that the weak signal associated with the single decode is all but invisible on the
+widegraph spectrogram.

doc/user_guide/en/tutorial-main-window.adoc

@@ -13,9 +13,6 @@ and *Page Up/Down* key presses, with the *Page* keys moving the
 controls in larger steps.  You can also type numbers directly into
 the spinner controls or use the mouse wheel.

-- Select *Tab 2* (below the *Decode* button) to choose the alternative
-set of controls for generating and selecting Tx messages.
-
 [[DOWNLOAD_SAMPLES]]
 === Download Samples


doc/user_guide/en/vhf-features.adoc

@@ -381,7 +381,7 @@ decode*, *Decode after EME delay*

 .Wide Graph:

-- *Bins/Pixel* = 3, *N Avg* = 10
+- *Bins/Pixel* = 4, *N Avg* = 10

 - Adjust the width of the window so that the frequency range extends
   up to at least 2400 Hz.

doc/user_guide/en/wsjtx-main.adoc

@@ -119,6 +119,15 @@ In macOS, enter the following command from a terminal:

  open /Applications/wsjtx.app --args -stylesheet :/qdarkstyle/style.qss

+In Linux using the Unity or GNOME GUI the following commands will
+update the _WSJT-X_ start up:
+
+....
+sed '/Exec=wsjtx/ s/$/ -stylesheet :\/qdarkstyle\/style.qss/' \
+  /usr/share/applications/wsjtx.desktop >~/.local/share/applications/wsjtx.desktop
+update-desktop-database ~/.local/share/applications/
+....
+
 Depending on your operating system, the main _WSJT-X_ window will look
 something like this:

@@ -193,7 +202,7 @@ include::wspr.adoc[]
 include::controls-functions-menus.adoc[]

 [[CONTROLS_MAIN]]
-=== Button Row
+    === Button Row
 include::controls-functions-main-window.adoc[]

 [[CONTROLS_LEFT]]

example_log_configurations/wsjtx_log_config.ini.rig_control

@@ -7,7 +7,7 @@ TargetFileName="${AppLocalDataLocation}/logs/wsjtx_syslog_%Y-%m.log"
 RotationTimePoint="01 00:00:00"
 Append=true
 EnableFinalRotation=false
-MaxSize=41943040
+MaxSize=52428800
 MinFreeSpace=1073741824
 MaxFiles=12
 Target="${AppLocalDataLocation}/logs"

lib/fst4_decode.f90

@@ -614,7 +614,7 @@ contains
                      endif
                      call this%callback(nutc,smax1,nsnr,xdt,fsig,msg,    &
                         iaptype,qual,ntrperiod,lwspr,fmid,w50)
-                     if(iwspr.eq.0 .and. nb.lt.0) go to 900
+!                     if(iwspr.eq.0 .and. nb.lt.0) go to 900
                      goto 800
                   endif
                enddo  ! metrics

lib/ft4/ft4code.f90

@@ -65,7 +65,8 @@ program ft4code
      if(i3.eq.2) msgtype="EU VHF Contest"
      if(i3.eq.3) msgtype="ARRL RTTY Roundup"
      if(i3.eq.4) msgtype="Nonstandard calls"
-     if(i3.ge.5) msgtype="Undefined msg type"
+     if(i3.eq.5) msgtype="EU VHF Contest"
+     if(i3.ge.6) msgtype="Undefined msg type"
      if(i3.ge.1) n3=-1
      bad=" "
      comment='         '

lib/ft8/ft8code.f90

@@ -64,7 +64,8 @@ program ft8code
      if(i3.eq.2) msgtype="EU VHF Contest"
      if(i3.eq.3) msgtype="ARRL RTTY Roundup"
      if(i3.eq.4) msgtype="Nonstandard call"
-     if(i3.ge.5) msgtype="Undefined type"
+     if(i3.eq.5) msgtype="EU VHF Contest"
+     if(i3.ge.6) msgtype="Undefined type"
      if(i3.ge.1) n3=-1
      bad=" "
      comment='         '

lib/msk144code.f90

@@ -51,7 +51,8 @@ program msk144code
      if(i3.eq.2) msgtype="EU VHF Contest"
      if(i3.eq.3) msgtype="ARRL RTTY Roundup"
      if(i3.eq.4) msgtype="Nonstandard calls"
-     if(i3.ge.5) msgtype="Undefined msg type"
+     if(i3.eq.5) msgtype="EU VHF Contest"
+     if(i3.ge.6) msgtype="Undefined msg type"
      if(i3.ge.1) n3=-1
      if(i4tone(41).lt.0) then
         msgtype="Sh msg"

lib/msk144decodeframe.f90

@@ -100,7 +100,7 @@ subroutine msk144decodeframe(c,softbits,msgreceived,nsuccess)
     nsuccess=1
     write(c77,'(77i1)') decoded77
     read(c77(72:77),'(2b3)') n3,i3
-    if( (i3.eq.0.and.(n3.eq.1 .or. n3.eq.3 .or. n3.eq.4 .or. n3.gt.5)) .or. i3.eq.3 .or. i3.gt.4 ) then
+    if( (i3.eq.0.and.(n3.eq.1 .or. n3.eq.3 .or. n3.eq.4 .or. n3.gt.5)) .or. i3.eq.3 .or. i3.gt.5 ) then
         nsuccess=0
     else
         call unpack77(c77,1,msgreceived,unpk77_success)

main.cpp

@@ -225,8 +225,7 @@ int main(int argc, char *argv[])
       // disallow multiple instances with same instance key
       QLockFile instance_lock {temp_dir.absoluteFilePath (a.applicationName () + ".lock")};
       instance_lock.setStaleLockTime (0);
-      bool lock_ok {false};
-      while (!(lock_ok = instance_lock.tryLock ()))
+      while (!instance_lock.tryLock ())
         {
           if (QLockFile::LockFailedError == instance_lock.error ())
             {
@@ -249,6 +248,10 @@ int main(int argc, char *argv[])
                   throw std::runtime_error {"Multiple instances must have unique rig names"};
                 }
             }
+          else
+            {
+              throw std::runtime_error {"Failed to access lock file"};
+            }
         }

       // load UI translations

samples/CMakeLists.txt

@@ -1,6 +1,10 @@
 set (SAMPLE_FILES
   FT4/000000_000002.wav
   FT8/181201_180245.wav
+  FST4+FST4W/210115_0058.wav
+  FST4+FST4W/201230_0300.wav
+  MSK144/181211_120500.wav
+  MSK144/181211_120800.wav
   ISCAT/ISCAT-A/VK7MO_110401_235515.wav
   ISCAT/ISCAT-B/K0AWU_100714_115000.wav
   JT4/JT4A/DF2ZC_070926_040700.WAV
@@ -17,6 +21,7 @@ set (SAMPLE_FILES
   JT9/130418_1742.wav
   MSK144/181211_120500.wav
   MSK144/181211_120800.wav
+  QRA64/QRA64C/161113_0111.wav
   WSPR/150426_0918.wav
   Q65/30A_Ionoscatter_6m/201203_022700.wav
   Q65/30A_Ionoscatter_6m/201203_022800.wav

widgets/AbstractLogWindow.cpp

@@ -64,7 +64,10 @@ void AbstractLogWindow::impl::delete_QSOs ()
                                                        , tr ("Confirm Delete")
                                                        , tr ("Are you sure you want to delete the %n "
                                                              "selected QSO(s) from the log?", ""
-                                                             , row_indexes.size ())))
+                                                             , row_indexes.size ())
+                                                       , QString {}
+                                                       , MessageBox::Yes | MessageBox::No
+                                                       , MessageBox::No))
     {
       // We must work with source model indexes because we don't want row
       // removes to invalidate model indexes we haven't yet processed. We

widgets/mainwindow.cpp

@@ -3633,7 +3633,7 @@ void MainWindow::auto_sequence (DecodedText const& message, unsigned start_toler
   auto const& message_words = message.messageWords ();
   auto is_73 = message_words.filter (QRegularExpression {"^(73|RR73)$"}).size();
   bool is_OK=false;
-  if(m_mode=="MSK144" and message.string().indexOf(ui->dxCallEntry->text()+" R ")>0) is_OK=true;
+  if(m_mode=="MSK144" and message.clean_string ().indexOf(ui->dxCallEntry->text()+" R ")>0) is_OK=true;
   if (message_words.size () > 2 && (message.isStandardMessage() || (is_73 or is_OK))) {
     auto df = message.frequencyOffset ();
     auto within_tolerance = (qAbs (ui->RxFreqSpinBox->value () - df) <= int (start_tolerance)
@@ -3648,7 +3648,7 @@ void MainWindow::auto_sequence (DecodedText const& message, unsigned start_toler
                || message_words.contains ("DE")))
           || !message.isStandardMessage ()); // free text 73/RR73

-    QStringList w=message.string().mid(22).remove("<").remove(">").split(" ",SkipEmptyParts);
+    QStringList w=message.clean_string ().mid(22).remove("<").remove(">").split(" ",SkipEmptyParts);
     QString w2;
     int nrpt=0;
     if (w.size () > 2)
@@ -3660,8 +3660,8 @@ void MainWindow::auto_sequence (DecodedText const& message, unsigned start_toler
         }
       }
     bool bEU_VHF=(nrpt>=520001 and nrpt<=594000);
-    if(bEU_VHF and message.string().contains("<"+m_config.my_callsign() + "> ")) {
-      m_xRcvd=message.string().trimmed().right(13);
+    if(bEU_VHF and message.clean_string ().contains("<"+m_config.my_callsign() + "> ")) {
+      m_xRcvd=message.clean_string ().trimmed().right(13);
     }
     if (m_auto
         && (m_QSOProgress==REPLYING  or (!ui->tx1->isEnabled () and m_QSOProgress==REPORT))
@@ -4180,7 +4180,7 @@ void MainWindow::guiUpdate()
           statusUpdate ();
         }
     }
-    m_bCallingCQ = CALLING == m_QSOProgress
+    m_bCallingCQ = 6 == m_ntx
       || m_currentMessage.contains (QRegularExpression {"^(CQ|QRZ) "});
     if(m_mode=="FT8" or m_mode=="FT4") {
       if(m_bCallingCQ && ui->cbFirst->isVisible () && ui->cbFirst->isChecked ()) {
@@ -4212,16 +4212,15 @@ void MainWindow::guiUpdate()
       msg_parts[1].remove (QChar {'<'});
       msg_parts[1].remove (QChar {'>'});
     }
-    auto is_73 = m_QSOProgress >= ROGER_REPORT
-      && message_is_73 (m_currentMessageType, msg_parts);
+    auto is_73 = message_is_73 (m_currentMessageType, msg_parts);
     m_sentFirst73 = is_73
       && !message_is_73 (m_lastMessageType, m_lastMessageSent.split (' ', SkipEmptyParts));
-    if (m_sentFirst73) {
+    if (m_sentFirst73 || (is_73 && CALLING == m_QSOProgress)) {
       m_qsoStop=t2;
       if(m_config.id_after_73 ()) {
         icw[0] = m_ncw;
       }
-      if((m_config.prompt_to_log() or m_config.autoLog()) && !m_tune) logQSOTimer.start(0);
+      if((m_config.prompt_to_log() or m_config.autoLog()) && !m_tune && CALLING != m_QSOProgress) logQSOTimer.start(0);
     }

     bool b=(m_mode=="FT8" or m_mode=="FT4") and ui->cbAutoSeq->isChecked();
@@ -4778,7 +4777,7 @@ void MainWindow::processMessage (DecodedText const& message, Qt::KeyboardModifie
   auto ctrl = modifiers.testFlag (Qt::ControlModifier);
   // auto alt = modifiers.testFlag (Qt::AltModifier);
   // basic mode sanity checks
-  auto const& parts = message.string ().split (' ', SkipEmptyParts);
+  auto const& parts = message.clean_string ().split (' ', SkipEmptyParts);
   if (parts.size () < 5) return;
   auto const& mode = parts.at (4).left (1);
   if (("JT65" == m_mode && mode != "#")
@@ -4827,16 +4826,16 @@ void MainWindow::processMessage (DecodedText const& message, Qt::KeyboardModifie
   QString hisgrid;
   message.deCallAndGrid(/*out*/hiscall,hisgrid);

-  if(message.string().contains(hiscall+"/R")) {
+  if(message.clean_string ().contains(hiscall+"/R")) {
     hiscall+="/R";
     ui->dxCallEntry->setText(hiscall);
   }
-  if(message.string().contains(hiscall+"/P")) {
+  if(message.clean_string ().contains(hiscall+"/P")) {
     hiscall+="/P";
     ui->dxCallEntry->setText(hiscall);
   }

-  QStringList w=message.string().mid(22).remove("<").remove(">").split(" ",SkipEmptyParts);
+  QStringList w=message.clean_string ().mid(22).remove("<").remove(">").split(" ",SkipEmptyParts);
   int nw=w.size();
   if(nw>=4) {
     if(message_words.size()<3) return;
@@ -4848,9 +4847,9 @@ void MainWindow::processMessage (DecodedText const& message, Qt::KeyboardModifie
   }

   bool is_73 = message_words.filter (QRegularExpression {"^(73|RR73)$"}).size ();
-  if (!is_73 and !message.isStandardMessage() and !message.string().contains("<")) {
+  if (!is_73 and !message.isStandardMessage() and !message.clean_string ().contains("<")) {
     qDebug () << "Not processing message - hiscall:" << hiscall << "hisgrid:" << hisgrid
-              << message.string() << message.isStandardMessage();
+              << message.clean_string () << message.isStandardMessage();
     return;
   }

@@ -4892,7 +4891,7 @@ void MainWindow::processMessage (DecodedText const& message, Qt::KeyboardModifie
   auto base_call = Radio::base_callsign (hiscall);

 // Determine appropriate response to received message
-  auto dtext = " " + message.string () + " ";
+  auto dtext = " " + message.clean_string () + " ";
   dtext=dtext.remove("<").remove(">");
   if(dtext.contains (" " + m_baseCall + " ")
      || dtext.contains ("<" + m_baseCall + "> ")
@@ -4920,7 +4919,7 @@ void MainWindow::processMessage (DecodedText const& message, Qt::KeyboardModifie
       MessageBox::information_message (this, msg);
     }

-    QStringList t=message.string().split(' ', SkipEmptyParts);
+    QStringList t=message.clean_string ().split(' ', SkipEmptyParts);
     int n=t.size();
     QString t0=t.at(n-2);
     QString t1=t0.right(1);
@@ -4996,11 +4995,11 @@ void MainWindow::processMessage (DecodedText const& message, Qt::KeyboardModifie
         }
       } else {  // no grid on end of msg
         auto const& word_3 = message_words.at (3);
-        bool word_3_is_int;
-        auto word_3_as_number = word_3.toInt (&word_3_is_int);
-        if(m_QSOProgress >= ROGER_REPORT && ("RRR" == word_3
-                                             || (word_3_is_int && word_3_as_number == 73)
-                                             || "RR73" == word_3)) {
+        auto word_3_as_number = word_3.toInt ();
+        if (("RRR" == word_3
+             || word_3_as_number == 73
+             || "RR73" == word_3
+             || ("R" == word_3 && m_QSOProgress != REPORT))) {
           if(m_mode=="FT4" and "RR73" == word_3) m_dateTimeRcvdRR73=QDateTime::currentDateTimeUtc();
           m_bTUmsg=false;
           m_nextCall="";   //### Temporary: disable use of "TU;" message
@@ -5013,16 +5012,30 @@ void MainWindow::processMessage (DecodedText const& message, Qt::KeyboardModifie
             ui->tx3->setText(t);
             m_bTUmsg=true;
           } else {
-            if(SpecOp::RTTY == m_config.special_op_id()) {
-              logQSOTimer.start(0);
-              m_ntx=6;
-              ui->txrb6->setChecked(true);
-            } else {
-              m_ntx=5;
-              ui->txrb5->setChecked(true);
-            }
+            if (m_QSOProgress > CALLING && m_QSOProgress < SIGNOFF
+                && SpecOp::NONE < m_config.special_op_id () && SpecOp::FOX > m_config.special_op_id ()
+                && ("RR73" == word_3 || 73 == word_3_as_number))
+              {
+                logQSOTimer.start(0);
+                m_ntx=6;
+                ui->txrb6->setChecked(true);
+              }
+            else if (word_3.contains (QRegularExpression {"^R(?!R73|RR)"})
+                     && m_QSOProgress != ROGER_REPORT)
+              {
+                m_ntx=4;
+                ui->txrb4->setChecked(true);
+              }
+            else
+              {
+                m_ntx=5;
+                ui->txrb5->setChecked(true);
+              }
           }
-          m_QSOProgress = SIGNOFF;
+          if (m_QSOProgress >= ROGER_REPORT)
+            {
+              m_QSOProgress = SIGNOFF;
+            }
         } else if((m_QSOProgress >= REPORT
                    || (m_QSOProgress >= REPLYING &&
                    (m_mode=="MSK144" or m_mode=="FT8" or m_mode=="FT4")))
@@ -5037,30 +5050,35 @@ void MainWindow::processMessage (DecodedText const& message, Qt::KeyboardModifie
           ui->txrb4->setChecked(true);
         } else if (m_QSOProgress >= CALLING)
           {
-            if (word_3_is_int
-                && ((word_3_as_number >= -50 && word_3_as_number <= 49)
-                    || (word_3_as_number >= 529 && word_3_as_number <= 599))) {
-              if(SpecOp::EU_VHF==m_config.special_op_id() or
-                 SpecOp::FIELD_DAY==m_config.special_op_id() or
-                 SpecOp::RTTY==m_config.special_op_id()) {
-                setTxMsg(2);
-                m_QSOProgress=REPORT;
+            if ((word_3_as_number >= -50 && word_3_as_number <= 49)
+                || (word_3_as_number >= 529 && word_3_as_number <= 599))
+              {
+                if(SpecOp::EU_VHF==m_config.special_op_id() or
+                   SpecOp::FIELD_DAY==m_config.special_op_id() or
+                   SpecOp::RTTY==m_config.special_op_id())
+                  {
+                    setTxMsg(2);
+                    m_QSOProgress=REPORT;
+                  }
+                else
+                  {
+                    if (word_3.startsWith ("R-") || word_3.startsWith ("R+"))
+                      {
+                        setTxMsg(4);
+                        m_QSOProgress=ROGERS;
+                      }
+                    else
+                      {
+                        setTxMsg (3);
+                        m_QSOProgress = ROGER_REPORT;
+                      }
+                  }
               }
-              else {
-                setTxMsg (3);
-                m_QSOProgress = ROGER_REPORT;
-              }
-            } else {
-              if (word_3.startsWith ("R-") || word_3.startsWith ("R+")) {
-                setTxMsg(4);
-                m_QSOProgress=ROGERS;
-            }
           }
-        }
-      else
-        {                // nothing for us
-          return;
-        }
+        else
+          {                // nothing for us
+            return;
+          }
       }
     }
     else if (m_QSOProgress >= ROGERS
@@ -5138,7 +5156,7 @@ void MainWindow::processMessage (DecodedText const& message, Qt::KeyboardModifie
   }

   QString s1 = m_QSOText.trimmed ();
-  QString s2 = message.string ().trimmed();
+  QString s2 = message.clean_string ().trimmed();
   if (s1!=s2 and !message.isTX()) {
     if (!s2.contains(m_baseCall) or m_mode=="MSK144") {  // Taken care of elsewhere if for_us and slow mode
       ui->decodedTextBrowser2->displayDecodedText(message, m_baseCall,m_mode,m_config.DXCC(),
@@ -5711,7 +5729,7 @@ void MainWindow::msgtype(QString t, QLineEdit* tx)               //msgtype()
       p.setColor(QPalette::Base,"#66ffff");     //light blue
     } else {
       p.setColor(QPalette::Base,Qt::transparent);
-      if(m_mode=="MSK144" and t.mid(0,1)=="<") {
+      if ("MSK144" == m_mode && t.count ('<') == 1) {
         p.setColor(QPalette::Base,"#00ffff");   //another light blue
       }
     }
@@ -6488,6 +6506,7 @@ void MainWindow::on_actionMSK144_triggered()
   } else {
     ui->labDXped->setVisible(true);
     ui->labDXped->setText(t0);
+    on_contest_log_action_triggered();
   }
 }
