README.md

@@ -2,7 +2,7 @@
 The purpose of this project is to transfer data (pictures...) via a 2,7kHz SSB channel on the narrow band transponder as fast as possible.

 # this is work in progress
-Version 0.1 is working on my linux PC and Odroid SBC.
+Version 0.2 is working on my linux PC, Odroid SBC and Raspberry 4 (3B+)

 # Prerequisites
 * LINUX Desktop PC ... working

grc/8psk_tx.grc

@@ -1,391 +0,0 @@
-options:
-  parameters:
-    author: kurt
-    category: '[GRC Hier Blocks]'
-    cmake_opt: ''
-    comment: 'requires GNU Radio 3.8xxx
-
-      does NOT work with 3.7x'
-    copyright: ''
-    description: requires GNU Radio 3.8xxx
-    gen_cmake: 'Off'
-    gen_linking: dynamic
-    generate_options: no_gui
-    hier_block_src_path: '.:'
-    id: tx_8psk
-    max_nouts: '0'
-    output_language: python
-    placement: (0,0)
-    qt_qss_theme: ''
-    realtime_scheduling: ''
-    run: 'True'
-    run_command: '{python} -u {filename}'
-    run_options: run
-    sizing_mode: fixed
-    thread_safe_setters: ''
-    title: 8PSK Modem  DJ0ABR
-    window_size: ''
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [8, 8]
-    rotation: 0
-    state: enabled
-
-blocks:
-- name: mixf
-  id: variable
-  parameters:
-    comment: 'mid frequency
-
-      in the audio
-
-      spectrum. Set to get
-
-      lowest and highest
-
-      frequency within the
-
-      transceiver filter range.'
-    value: '1500'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [336, 12.0]
-    rotation: 0
-    state: enabled
-- name: nfilts
-  id: variable
-  parameters:
-    comment: ''
-    value: '32'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [504, 12.0]
-    rotation: 0
-    state: enabled
-- name: sps
-  id: variable
-  parameters:
-    comment: 'Samples/Symbol
-
-      fixed value,
-
-      do not change.
-
-      Used to adjust
-
-      bitrate vs. bandwidth'
-    value: '1'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [944, 36.0]
-    rotation: 0
-    state: enabled
-- name: analog_sig_source_x_0_0_0
-  id: analog_sig_source_x
-  parameters:
-    affinity: ''
-    alias: ''
-    amp: '1'
-    comment: 'the modulator output is in the baseband at 0 Hz.
-
-      Mix it with the required audio mid frequency.
-
-      cos and -sin are used to combine I and Q
-
-      into the final signal.'
-    freq: mixf
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    offset: '0'
-    phase: '0'
-    samp_rate: samp_rate
-    type: complex
-    waveform: analog.GR_COS_WAVE
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [64, 484.0]
-    rotation: 0
-    state: enabled
-- name: audio_sink_0_0
-  id: audio_sink
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: 'send audio to
-
-      transceiver'
-    device_name: ''
-    num_inputs: '1'
-    ok_to_block: 'True'
-    samp_rate: samp_rate
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [840, 420.0]
-    rotation: 0
-    state: enabled
-- name: blocks_add_xx_0
-  id: blocks_add_xx
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: 'generate the analog
-
-      output signal.'
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    num_inputs: '2'
-    type: float
-    vlen: '1'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [568, 344.0]
-    rotation: 0
-    state: true
-- name: blocks_complex_to_float_1
-  id: blocks_complex_to_float
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: ''
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    vlen: '1'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [400, 344.0]
-    rotation: 0
-    state: enabled
-- name: blocks_multiply_const_vxx_0
-  id: blocks_multiply_const_vxx
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: 'reduce level for the
-
-      audio output, improves
-
-      linearity'
-    const: '0.05'
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    type: float
-    vlen: '1'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [680, 420.0]
-    rotation: 0
-    state: true
-- name: blocks_multiply_xx_0_0
-  id: blocks_multiply_xx
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: "mix I und Q \nto the mid \nfrequency\nspecified in\n\"mixf\""
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    num_inputs: '2'
-    type: complex
-    vlen: '1'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [288, 344.0]
-    rotation: 0
-    state: enabled
-- name: blocks_udp_source_0
-  id: blocks_udp_source
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: "receive an UDP data stream\nwith the bitrate of (see \ncomment samp_rate)\n\
-      The stream is buffered, \nso send some bytes ahead\nto prefill the buffer\n\
-      and avoid underrun"
-    eof: 'False'
-    ipaddr: 127.0.0.1
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    port: '40134'
-    psize: '258'
-    type: byte
-    vlen: '1'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [736, 164.0]
-    rotation: 180
-    state: true
-- name: digital_constellation_modulator_0
-  id: digital_constellation_modulator
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: 'This modulator expects "Packed Bytes"
-
-      which are 8 bits within one byte.
-
-      The UDP source block deliveres bytes,
-
-      so it fits perfectly.'
-    constellation: digital.constellation_8psk_natural().base()
-    differential: 'True'
-    excess_bw: '0.25'
-    log: 'False'
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    samples_per_symbol: resamprate
-    verbose: 'False'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [272, 172.0]
-    rotation: 180
-    state: enabled
-- name: qtgui_freq_sink_x_0
-  id: qtgui_freq_sink_x
-  parameters:
-    affinity: ''
-    alias: ''
-    alpha1: '1.0'
-    alpha10: '1.0'
-    alpha2: '1.0'
-    alpha3: '1.0'
-    alpha4: '1.0'
-    alpha5: '1.0'
-    alpha6: '1.0'
-    alpha7: '1.0'
-    alpha8: '1.0'
-    alpha9: '1.0'
-    autoscale: 'False'
-    average: '0.1'
-    axislabels: 'True'
-    bw: samp_rate
-    color1: '"blue"'
-    color10: '"dark blue"'
-    color2: '"red"'
-    color3: '"green"'
-    color4: '"black"'
-    color5: '"cyan"'
-    color6: '"magenta"'
-    color7: '"yellow"'
-    color8: '"dark red"'
-    color9: '"dark green"'
-    comment: ''
-    ctrlpanel: 'False'
-    fc: '0'
-    fftsize: '1024'
-    freqhalf: 'False'
-    grid: 'True'
-    gui_hint: ''
-    label: Relative Gain
-    label1: ''
-    label10: ''''''
-    label2: ''''''
-    label3: ''''''
-    label4: ''''''
-    label5: ''''''
-    label6: ''''''
-    label7: ''''''
-    label8: ''''''
-    label9: ''''''
-    legend: 'True'
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    name: '""'
-    nconnections: '1'
-    showports: 'False'
-    tr_chan: '0'
-    tr_level: '0.0'
-    tr_mode: qtgui.TRIG_MODE_FREE
-    tr_tag: '""'
-    type: float
-    units: dB
-    update_time: '0.10'
-    width1: '1'
-    width10: '1'
-    width2: '1'
-    width3: '1'
-    width4: '1'
-    width5: '1'
-    width6: '1'
-    width7: '1'
-    width8: '1'
-    width9: '1'
-    wintype: firdes.WIN_BLACKMAN_hARRIS
-    ymax: '10'
-    ymin: '-140'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [552, 552.0]
-    rotation: 0
-    state: disabled
-- name: resamprate
-  id: parameter
-  parameters:
-    alias: ''
-    comment: ''
-    hide: none
-    label: resamprate
-    short_id: r
-    type: intx
-    value: '24'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [808, 12.0]
-    rotation: 0
-    state: true
-- name: samp_rate
-  id: parameter
-  parameters:
-    alias: ''
-    comment: Audio Rate
-    hide: none
-    label: samp_rate
-    short_id: s
-    type: intx
-    value: '48000'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [696, 12.0]
-    rotation: 0
-    state: true
-
-connections:
-- [analog_sig_source_x_0_0_0, '0', blocks_multiply_xx_0_0, '1']
-- [blocks_add_xx_0, '0', blocks_multiply_const_vxx_0, '0']
-- [blocks_add_xx_0, '0', qtgui_freq_sink_x_0, '0']
-- [blocks_complex_to_float_1, '0', blocks_add_xx_0, '0']
-- [blocks_complex_to_float_1, '1', blocks_add_xx_0, '1']
-- [blocks_multiply_const_vxx_0, '0', audio_sink_0_0, '0']
-- [blocks_multiply_xx_0_0, '0', blocks_complex_to_float_1, '0']
-- [blocks_udp_source_0, '0', digital_constellation_modulator_0, '0']
-- [digital_constellation_modulator_0, '0', blocks_multiply_xx_0_0, '0']
-
-metadata:
-  file_format: 1

grc/txuniversal_qpsk_nogui_ownmod.grc

@@ -1,383 +0,0 @@
-options:
-  parameters:
-    author: DJ0ABR
-    category: '[GRC Hier Blocks]'
-    cmake_opt: ''
-    comment: 'requires GNU Radio 3.8xxx
-
-      does NOT work with 3.7x'
-    copyright: DJ0ABR
-    description: requires GNU Radio 3.8xxx
-    gen_cmake: 'On'
-    gen_linking: dynamic
-    generate_options: no_gui
-    hier_block_src_path: '.:'
-    id: qpsk_tx
-    max_nouts: '0'
-    output_language: python
-    placement: (0,0)
-    qt_qss_theme: ''
-    realtime_scheduling: ''
-    run: 'True'
-    run_command: '{python} -u {filename}'
-    run_options: run
-    sizing_mode: fixed
-    thread_safe_setters: ''
-    title: 'QPSK TX-Modem '
-    window_size: ''
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [8, 8]
-    rotation: 0
-    state: enabled
-
-blocks:
-- name: mixf
-  id: variable
-  parameters:
-    comment: 'mid frequency
-
-      in the audio
-
-      spectrum. Set to get
-
-      lowest and highest
-
-      frequency within the
-
-      transceiver filter range.'
-    value: '1500'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [360, 12.0]
-    rotation: 0
-    state: enabled
-- name: qpsk__constellation
-  id: variable_constellation_rect
-  parameters:
-    comment: 'alternative:
-
-      [0.707+0.707j, -0.707+0.707j, -0.707-0.707j, 0.707-0.707j]
-
-      does not make a difference'
-    const_points: '[1+1j, -1+1j, -1-1j, 1-1j]'
-    imag_sect: '2'
-    precision: '8'
-    real_sect: '2'
-    rot_sym: '4'
-    soft_dec_lut: None
-    sym_map: '[0, 1, 2, 3]'
-    w_imag_sect: '1'
-    w_real_sect: '1'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [8, 196.0]
-    rotation: 0
-    state: enabled
-- name: analog_sig_source_x_0_0_0
-  id: analog_sig_source_x
-  parameters:
-    affinity: ''
-    alias: ''
-    amp: '1'
-    comment: 'the modulator output is in the baseband at 0 Hz.
-
-      Mix it with the required audio mid frequency.
-
-      cos and -sin are used to combine I and Q
-
-      into the final signal.'
-    freq: mixf
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    offset: '0'
-    phase: '0'
-    samp_rate: samp_rate
-    type: complex
-    waveform: analog.GR_COS_WAVE
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [96, 476.0]
-    rotation: 0
-    state: enabled
-- name: audio_sink_0_0
-  id: audio_sink
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: 'send audio to
-
-      transceiver'
-    device_name: ''
-    num_inputs: '1'
-    ok_to_block: 'True'
-    samp_rate: samp_rate
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [928, 356.0]
-    rotation: 0
-    state: enabled
-- name: blocks_add_xx_0
-  id: blocks_add_xx
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: 'generate the analog
-
-      output signal: USB
-
-      (for LSB use substraction)'
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    num_inputs: '2'
-    type: float
-    vlen: '1'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [696, 376.0]
-    rotation: 0
-    state: true
-- name: blocks_complex_to_float_1
-  id: blocks_complex_to_float
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: ''
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    vlen: '1'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [512, 376.0]
-    rotation: 0
-    state: enabled
-- name: blocks_multiply_const_vxx_0
-  id: blocks_multiply_const_vxx
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: 'reduce level for the
-
-      audio output, improves
-
-      linearity'
-    const: '0.05'
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    type: float
-    vlen: '1'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [784, 356.0]
-    rotation: 0
-    state: true
-- name: blocks_multiply_xx_0_0
-  id: blocks_multiply_xx
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: "mix I und Q \nto the mid \nfrequency\nspecified in\n\"mixf\""
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    num_inputs: '2'
-    type: complex
-    vlen: '1'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [400, 376.0]
-    rotation: 0
-    state: enabled
-- name: blocks_udp_source_0
-  id: blocks_udp_source
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: "receive an UDP data stream\nwith the bitrate of (see \ncomment samp_rate)\n\
-      The stream is buffered, \nso send some bytes ahead\nto prefill the buffer\n\
-      and avoid underrun"
-    eof: 'False'
-    ipaddr: 127.0.0.1
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    port: '40134'
-    psize: '258'
-    type: byte
-    vlen: '1'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [824, 148.0]
-    rotation: 180
-    state: enabled
-- name: digital_constellation_modulator_0
-  id: digital_constellation_modulator
-  parameters:
-    affinity: ''
-    alias: ''
-    comment: 'unpack bytes to bits
-
-      make symbols 2bits/sym
-
-      make constellation'
-    constellation: qpsk__constellation
-    differential: 'False'
-    excess_bw: '0.35'
-    log: 'False'
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    samples_per_symbol: resamprate
-    verbose: 'False'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [392, 180.0]
-    rotation: 180
-    state: enabled
-- name: qtgui_freq_sink_x_0
-  id: qtgui_freq_sink_x
-  parameters:
-    affinity: ''
-    alias: ''
-    alpha1: '1.0'
-    alpha10: '1.0'
-    alpha2: '1.0'
-    alpha3: '1.0'
-    alpha4: '1.0'
-    alpha5: '1.0'
-    alpha6: '1.0'
-    alpha7: '1.0'
-    alpha8: '1.0'
-    alpha9: '1.0'
-    autoscale: 'False'
-    average: '0.1'
-    axislabels: 'True'
-    bw: samp_rate
-    color1: '"blue"'
-    color10: '"dark blue"'
-    color2: '"red"'
-    color3: '"green"'
-    color4: '"black"'
-    color5: '"cyan"'
-    color6: '"magenta"'
-    color7: '"yellow"'
-    color8: '"dark red"'
-    color9: '"dark green"'
-    comment: ''
-    ctrlpanel: 'False'
-    fc: '0'
-    fftsize: '1024'
-    freqhalf: 'False'
-    grid: 'True'
-    gui_hint: ''
-    label: Relative Gain
-    label1: ''
-    label10: ''''''
-    label2: ''''''
-    label3: ''''''
-    label4: ''''''
-    label5: ''''''
-    label6: ''''''
-    label7: ''''''
-    label8: ''''''
-    label9: ''''''
-    legend: 'True'
-    maxoutbuf: '0'
-    minoutbuf: '0'
-    name: '""'
-    nconnections: '1'
-    showports: 'False'
-    tr_chan: '0'
-    tr_level: '0.0'
-    tr_mode: qtgui.TRIG_MODE_FREE
-    tr_tag: '""'
-    type: float
-    units: dB
-    update_time: '0.10'
-    width1: '1'
-    width10: '1'
-    width2: '1'
-    width3: '1'
-    width4: '1'
-    width5: '1'
-    width6: '1'
-    width7: '1'
-    width8: '1'
-    width9: '1'
-    wintype: firdes.WIN_BLACKMAN_hARRIS
-    ymax: '10'
-    ymin: '-140'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [880, 576.0]
-    rotation: 0
-    state: disabled
-- name: resamprate
-  id: parameter
-  parameters:
-    alias: ''
-    comment: ''
-    hide: none
-    label: resamprate
-    short_id: r
-    type: intx
-    value: '20'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [776, 12.0]
-    rotation: 0
-    state: true
-- name: samp_rate
-  id: parameter
-  parameters:
-    alias: ''
-    comment: Audio Rate
-    hide: none
-    label: samp_rate
-    short_id: s
-    type: intx
-    value: '44100'
-  states:
-    bus_sink: false
-    bus_source: false
-    bus_structure: null
-    coordinate: [208, 12.0]
-    rotation: 0
-    state: true
-
-connections:
-- [analog_sig_source_x_0_0_0, '0', blocks_multiply_xx_0_0, '1']
-- [blocks_add_xx_0, '0', blocks_multiply_const_vxx_0, '0']
-- [blocks_add_xx_0, '0', qtgui_freq_sink_x_0, '0']
-- [blocks_complex_to_float_1, '0', blocks_add_xx_0, '0']
-- [blocks_complex_to_float_1, '1', blocks_add_xx_0, '1']
-- [blocks_multiply_const_vxx_0, '0', audio_sink_0_0, '0']
-- [blocks_multiply_xx_0_0, '0', blocks_complex_to_float_1, '0']
-- [blocks_udp_source_0, '0', digital_constellation_modulator_0, '0']
-- [digital_constellation_modulator_0, '0', blocks_multiply_xx_0_0, '0']
-
-metadata:
-  file_format: 1

modem/Makefile

@@ -1,8 +1,11 @@
+# Makefile for qo100modem
+# =======================
+
 CFLAGS=-O3 -Wall
-LDLIBS= -L. -lpthread -lfftw3 -lm -lzip
+LDLIBS= -L. -lpthread -lfftw3 -lm -lzip -lfftw3_threads -lsndfile -lasound -lbass -lliquid
 CC=c++
 PROGNAME=qo100modem
-OBJ=qo100modem.o main_helper.o udp.o frame_packer.o scrambler.o crc16.o fec.o fft.o constellation.o arraysend.o
+OBJ=qo100modem.o main_helper.o udp.o frame_packer.o scrambler.o crc16.o fec.o fft.o constellation.o arraysend.o audio.o liquid_if.o

 all: qo100modem


modem/arraysend.c

@@ -120,7 +120,12 @@ void doArraySend()
     {
         // send first frame
         printf("Start Array Send %d\n",getSending());
-        toGR_Preamble();
+
+        // preamble
+        int numframespreamble = 3* ((caprate/txinterpolfactor) * bitsPerSymbol / 8) /258 + 1;
+        for(int i=0; i<numframespreamble; i++)
+            toGR_sendData(TXarray, txtype, filestat);
+
         if(txlen <= PAYLOADLEN)
         {
             // we just need to send one frame

modem/audio.c

@@ -0,0 +1,245 @@
+/*
+* High Speed modem to transfer data in a 2,7kHz SSB channel
+* =========================================================
+* Author: DJ0ABR
+*
+*   (c) DJ0ABR
+*   www.dj0abr.de
+*
+*   This program is free software; you can redistribute it and/or modify
+*   it under the terms of the GNU General Public License as published by
+*   the Free Software Foundation; either version 2 of the License, or
+*   (at your option) any later version.
+*
+*   This program is distributed in the hope that it will be useful,
+*   but WITHOUT ANY WARRANTY; without even the implied warranty of
+*   MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
+*   GNU General Public License for more details.
+*
+*   You should have received a copy of the GNU General Public License
+*   along with this program; if not, write to the Free Software
+*   Foundation, Inc., 675 Mass Ave, Cambridge, MA 02139, USA.
+*
+* audio.c ... functions to handle audio in/out via a soundcard
+*             uses the "BASS" library
+*
+* captures samples from the sound card.
+* Samples are 32-bit floats in a range of -1 to +1
+* get these samples from the thread safe fifo: cap_read_fifo(&floatvariable)
+*
+* plays samples to the sound card
+* Samples are 32-bit floats in a range of -1 to +1
+* play the samples by calling the thread save function: pb_write_fifo(floatsample)
+*
+*/
+
+#include "qo100modem.h"
+
+//BOOL CALLBACK RecordingCallback(HRECORD handle, const void *buffer, DWORD length, void *user);
+DWORD CALLBACK WriteStream(HSTREAM handle, float *buffer, DWORD length, void *user);
+int pb_read_fifo(float *data, int elements);
+void close_audio();
+
+#define CHANNELS 1      // no of channels used
+
+HRECORD rchan = 0;		// recording channel
+BASS_INFO info;
+HSTREAM stream = 0;
+
+int init_audio()
+{
+    close_audio();
+    printf("init audio, caprate:%d\n",caprate);
+
+    // check the correct BASS was loaded
+	if (HIWORD(BASS_GetVersion()) != BASSVERSION)
+    {
+		printf("An incorrect version of BASS was loaded\n");
+        return -1;
+	}
+	/*
+	// initalize default recording device
+	if (!BASS_RecordInit(-1))
+    {
+		printf("Can't initialize recording device\n");
+        return -1;
+	}
+	*/
+	// initialize default output device
+	if (!BASS_Init(-1, caprate, 0, NULL, NULL))
+    {
+		printf("Can't initialize output device\n");
+        return -1;
+    }
+    /*
+    // set capture callback
+    rchan = BASS_RecordStart(caprate, CHANNELS, BASS_SAMPLE_FLOAT, RecordingCallback, 0);
+	if (!rchan) {
+		printf("Can't start capturing\n");
+		return -1;
+	}
+	*/
+	// set play callback
+	BASS_GetInfo(&info);
+	stream = BASS_StreamCreate(info.freq, CHANNELS, BASS_SAMPLE_FLOAT, (STREAMPROC*)WriteStream, 0); // sample: 32 bit float
+	BASS_ChannelSetAttribute(stream, BASS_ATTRIB_BUFFER, 0); // no buffering for minimum latency
+	BASS_ChannelPlay(stream, FALSE); // start it
+
+    return 0;
+}
+
+void close_audio()
+{
+    if(stream != 0)
+    {
+        //BASS_RecordFree();
+        int r = BASS_Free();
+        if(!r)
+            printf("Bass_free error: %d\n", BASS_ErrorGetCode());
+        stream = 0;
+    }
+}
+/*
+// capture callback
+// length: bytes. short=2byte, 2channels, so it requests samples*4
+BOOL CALLBACK RecordingCallback(HRECORD handle, const void *buffer, DWORD length, void *user)
+{
+    //printf("captured %ld samples\n",length/sizeof(float));
+
+    float *fbuffer = (float *)buffer;
+    //printf("w:%ld ",length/sizeof(float));
+    for(int i=0; i<(length/sizeof(float)); i+=CHANNELS)
+    {
+        //printf("%f\n",fbuffer[i]);
+        cap_write_fifo(fbuffer[i]);
+    }
+
+    return TRUE; // continue recording
+}
+*/
+// play callback
+// length: bytes. float=4byte, 2channels, so it requests samples*8
+DWORD CALLBACK WriteStream(HSTREAM handle, float *buffer, DWORD length, void *user)
+{
+    int ret = pb_read_fifo(buffer,length/sizeof(float));
+    if(ret == 0)
+    {
+        // fifo empty, send 00
+        memset(buffer,0,length);
+    }
+	return length;
+}
+
+// ================ thread safe fifo for audio callback routines ===============
+
+pthread_mutex_t cap_crit_sec;
+pthread_mutex_t pb_crit_sec;
+#define CAP_LOCK	pthread_mutex_lock(&cap_crit_sec)
+#define CAP_UNLOCK	pthread_mutex_unlock(&cap_crit_sec)
+#define PB_LOCK	pthread_mutex_lock(&pb_crit_sec)
+#define PB_UNLOCK	pthread_mutex_unlock(&pb_crit_sec)
+
+#define AUDIO_BUFFERMAXTIME 2  // fifo can buffer this time in [s]
+#define AUDIO_PLAYBACK_BUFLEN (48000 * 10) // space for 10 seconds of samples
+/*#define AUDIO_CAPTURE_BUFLEN  (48000*CHANNELS*AUDIO_BUFFERMAXTIME*UPSAMPLING)
+
+int cap_wridx=0;
+int cap_rdidx=0;
+float cap_buffer[AUDIO_CAPTURE_BUFLEN];
+*/
+int pb_wridx=0;
+int pb_rdidx=0;
+float pb_buffer[AUDIO_PLAYBACK_BUFLEN];
+
+/*
+// write one sample into the fifo
+// overwrite old data if the fifo is full
+void cap_write_fifo(float sample)
+{
+	CAP_LOCK;
+    cap_buffer[cap_wridx] = sample;
+    if(++cap_wridx >= AUDIO_CAPTURE_BUFLEN) cap_wridx = 0;
+	CAP_UNLOCK;
+}
+
+int cap_read_fifo(float *data)
+{
+	CAP_LOCK;
+
+	if (cap_rdidx == cap_wridx)
+	{
+		// Fifo empty, no data available
+		CAP_UNLOCK;
+		return 0;
+	}
+
+	*data = cap_buffer[cap_rdidx];
+    if(++cap_rdidx >= AUDIO_CAPTURE_BUFLEN) cap_rdidx = 0;
+    CAP_UNLOCK;
+
+	return 1;
+}
+*/
+void pb_write_fifo(float sample)
+{
+	PB_LOCK;
+
+    // check if there is free space in fifo
+    if(pb_fifo_freespace(1) == 0)
+    {
+        PB_UNLOCK;
+        printf("************* pb fifo full\n");
+        return;
+    }
+
+    pb_buffer[pb_wridx] = sample;
+    if(++pb_wridx >= AUDIO_PLAYBACK_BUFLEN) pb_wridx = 0;
+	PB_UNLOCK;
+    //printf("write: pbw:%d pbr:%d\n",pb_wridx,pb_rdidx);
+}
+
+int pb_fifo_freespace(int nolock)
+{
+int freebuf = 0;
+
+    if(nolock == 0) PB_LOCK;
+
+    /*freebuf = AUDIO_PLAYBACK_BUFLEN - ((pb_wridx+AUDIO_PLAYBACK_BUFLEN+1 - pb_rdidx)%AUDIO_PLAYBACK_BUFLEN);
+    freebuf %= AUDIO_PLAYBACK_BUFLEN;*/
+
+    int elemInFifo = (pb_wridx + AUDIO_PLAYBACK_BUFLEN - pb_rdidx) % AUDIO_PLAYBACK_BUFLEN;
+    freebuf = AUDIO_PLAYBACK_BUFLEN - elemInFifo;
+
+	if(nolock == 0) PB_UNLOCK;
+
+    //printf("fifolen:%d check: pbw:%d pbr:%d freebuf:%d\n",AUDIO_PLAYBACK_BUFLEN,pb_wridx,pb_rdidx,freebuf);
+
+    return freebuf;
+}
+
+// read elements floats from fifo or return 0 if not enough floats are available
+int pb_read_fifo(float *data, int elements)
+{
+    //printf("pb read fifo: %d\n",elements);
+	PB_LOCK;
+
+    int e = AUDIO_PLAYBACK_BUFLEN - pb_fifo_freespace(1);
+    //if (pb_rdidx == pb_wridx)
+    if(e < elements)
+	{
+		// Fifo empty, no data available
+		PB_UNLOCK;
+        //printf("pb fifo empty, need:%d have:%d size:%d\n",elements,e,AUDIO_PLAYBACK_BUFLEN);
+		return 0;
+	}
+
+    for(int i=0; i<elements; i++)
+    {
+        data[i] = pb_buffer[pb_rdidx];
+        if(++pb_rdidx >= AUDIO_PLAYBACK_BUFLEN) pb_rdidx = 0;
+    }
+    //printf("read %d floats\n",elements);
+
+    PB_UNLOCK;
+    return 1;
+}

modem/fec_fast.c

@@ -1,67 +0,0 @@
-/*
-* High Speed modem to transfer data in a 2,7kHz SSB channel
-* =========================================================
-* Author: DJ0ABR
-*
-*   (c) DJ0ABR
-*   www.dj0abr.de
-*
-*   This program is free software; you can redistribute it and/or modify
-*   it under the terms of the GNU General Public License as published by
-*   the Free Software Foundation; either version 2 of the License, or
-*   (at your option) any later version.
-*
-*   This program is distributed in the hope that it will be useful,
-*   but WITHOUT ANY WARRANTY; without even the implied warranty of
-*   MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
-*   GNU General Public License for more details.
-*
-*   You should have received a copy of the GNU General Public License
-*   along with this program; if not, write to the Free Software
-*   Foundation, Inc., 675 Mass Ave, Cambridge, MA 02139, USA.
-*
-*/
-
-#include "qo100modem.h"
-#include "liquid.h"
-
-fec fecobjTX;
-fec fecobjRX;
-fec_scheme fs = LIQUID_FEC_SECDED3932;   // error-correcting scheme
-uint8_t encoded_message[UdpBlocklen];
-uint8_t decoded_message[PayloadLen+framenumlen+CRClen];
-
-uint8_t *cfec_Reconstruct(uint8_t *darr)
-{
-    memset(decoded_message,0,(PayloadLen+framenumlen+CRClen));
-    fec_decode(fecobjRX, (PayloadLen+framenumlen+CRClen), darr, decoded_message);
-
-    return decoded_message;
-}
-
-uint8_t *GetFEC(uint8_t *txblock, int len)
-{
-    if(len != (PayloadLen+framenumlen+CRClen))
-    {
-        printf("wrong FEC encode length, len:%d Payloadlen:%d\n",len,PayloadLen);
-        exit(0);
-    }
-
-    fec_encode(fecobjTX, len, txblock, encoded_message);
-
-    return encoded_message;
-}
-
-void initFEC()
-{
-    int n_enc = fec_get_enc_msg_length(fs,(PayloadLen+framenumlen+CRClen));
-    if(n_enc != UdpBlocklen)
-    {
-        printf("wrong FEC init length\n");
-        exit(0);
-    }
-
-    fecobjTX = fec_create(fs,NULL);
-    fecobjRX = fec_create(fs,NULL);
-}
-

modem/frame_packer.c

@@ -138,7 +138,7 @@ uint8_t *Pack(uint8_t *payload, int type, int status, int *plen)
     }
 }*/

-#define MAXHEADERRS  0
+#define MAXHEADERRS  3

 /*
  * Header erros will not cause any data errors because the CRC will filter out
@@ -298,7 +298,7 @@ uint8_t *getPayload(uint8_t *rxb)
     int framenumrx = (frame.status & 0xc0)>>6;  // frame counter MSB
     framenumrx <<= 8;
     framenumrx += frame.counter_LSB;        // frame counter LSB
-    //printf("Frame no.: %d\n",framenumrx);
+
     if (lastframenum != framenumrx) rx_status |= 4;
     lastframenum = framenumrx;
     if (++lastframenum >= 1024) lastframenum = 0; // 1024 = 2^10 (10 bit frame number)
@@ -317,6 +317,8 @@ uint8_t *getPayload(uint8_t *rxb)
     payload[8] = 0;
     payload[9] = 0;

+    //printf("Frame no.: %d, type:%d, minfo:%d\n",framenumrx,payload[0],payload[3]);
+
     memcpy(payload+10,frame.payload,PAYLOADLEN);

     return payload;

modem/liquid-dsp-install

@@ -0,0 +1,9 @@
+sudo apt install git autoconf libsndfile-dev libasound-dev
+git clone git://github.com/jgaeddert/liquid-dsp.git
+cd liquid-dsp
+./bootstrap.sh
+./configure
+make -j 8
+sudo make install
+sudo ldconfig
+

modem/liquid_if.c

@@ -0,0 +1,171 @@
+/*
+* High Speed modem to transfer data in a 2,7kHz SSB channel
+* =========================================================
+* Author: DJ0ABR
+*
+*   (c) DJ0ABR
+*   www.dj0abr.de
+*
+*   This program is free software; you can redistribute it and/or modify
+*   it under the terms of the GNU General Public License as published by
+*   the Free Software Foundation; either version 2 of the License, or
+*   (at your option) any later version.
+*
+*   This program is distributed in the hope that it will be useful,
+*   but WITHOUT ANY WARRANTY; without even the implied warranty of
+*   MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
+*   GNU General Public License for more details.
+*
+*   You should have received a copy of the GNU General Public License
+*   along with this program; if not, write to the Free Software
+*   Foundation, Inc., 675 Mass Ave, Cambridge, MA 02139, USA.
+*
+* liquid_dsp_interface.c ... functions using liquid-dsp
+*
+* liquid-dsp must be previously installed by running ./liquid-dsp-install (under linux)
+*
+*/
+
+#include "qo100modem.h"
+
+void modulator(uint8_t sym_in);
+void close_dsp();
+
+// modem objects
+modulation_scheme ms    = LIQUID_MODEM_QPSK;
+modem mod = NULL;
+
+// NCOs for mixing baseband <-> 1500 Hz
+#define FREQUENCY           1500
+int      type        = LIQUID_NCO;                  // nco type
+nco_crcf upnco = NULL;
+
+// TX-Interpolator Filter Parameters
+// 44100 input rate for 2205 Sym/s = 20
+// change for other rates
+firinterp_crcf TX_interpolator = NULL;
+unsigned int k_SampPerSymb =            20;         // 44100 / (4410/2)
+unsigned int m_filterDelay_Symbols =    15;         // not too short for good filter
+float        beta_excessBW  =           0.3f;      // filter excess bandwidth factor
+float        tau_FracSymbOffset   =     -0.2f;      // fractional symbol offset
+
+int init_dsp()
+{
+    close_dsp();
+    printf("create DSP\n");
+
+    k_SampPerSymb = txinterpolfactor;
+    if(bitsPerSymbol == 2)
+        ms = LIQUID_MODEM_QPSK;
+    else
+        ms = LIQUID_MODEM_DPSK8;
+
+    // create modulator
+    mod = modem_create(ms);
+
+    // create NCO for upmixing to 1500 Hz
+    double RADIANS_PER_SAMPLE   = ((2.0*M_PI*(double)FREQUENCY)/(float)caprate);
+
+    upnco = nco_crcf_create(LIQUID_NCO);
+    nco_crcf_set_phase(upnco, 0.0f);
+    nco_crcf_set_frequency(upnco, RADIANS_PER_SAMPLE);
+
+    // TX: Interpolator Filter
+    // compute delay
+    while (tau_FracSymbOffset < 0) tau_FracSymbOffset += 1.0f;  // ensure positive tau
+    float g = k_SampPerSymb*tau_FracSymbOffset;                 // number of samples offset
+    int ds=floorf(g);               // additional symbol delay
+    float dt = (g - (float)ds);     // fractional sample offset
+    // force dt to be in [0.5,0.5]
+    if (dt > 0.5f)
+    {
+        dt -= 1.0f;
+        ds++;
+    }
+
+    // calculate filter coeffs
+    unsigned int h_len_NumFilterCoeefs = 2 * k_SampPerSymb * m_filterDelay_Symbols + 1;
+    float h[h_len_NumFilterCoeefs];
+    liquid_firdes_prototype(    LIQUID_FIRFILT_RRC,
+                                k_SampPerSymb,
+                                m_filterDelay_Symbols,
+                                beta_excessBW,
+                                dt,
+                                h);
+    // create the filter
+    TX_interpolator = firinterp_crcf_create(k_SampPerSymb,h,h_len_NumFilterCoeefs);
+
+    printf("DSP created\n");
+    return 1;
+}
+
+void close_dsp()
+{
+    if(mod != NULL) modem_destroy(mod);
+    if(upnco != NULL) nco_crcf_destroy(upnco);
+    if(TX_interpolator != NULL) firinterp_crcf_destroy(TX_interpolator);
+    mod = NULL;
+    upnco = NULL;
+    TX_interpolator = NULL;
+}
+
+// d ... symbols to send
+// len ... number of symbols in d
+void sendToModulator(uint8_t *d, int len)
+{
+
+    //printf("sendToModulator %d bytes\n",len);
+
+    int symanz = len * 8 / bitsPerSymbol;
+    uint8_t syms[symanz];
+    if(bitsPerSymbol == 2)
+        convertBytesToSyms_QPSK(d, syms, len);
+    else
+        convertBytesToSyms_8PSK(d, syms, len);
+
+    for(int i=0; i<symanz; i++)
+    {
+        // remove gray code
+        // this adds gray code, liquid adds it again which removes it
+        syms[i] ^= (syms[i]>>1);
+
+        modulator(syms[i]);
+    }
+}
+
+// call for every symbol
+// modulates, filters and upmixes symbols and send it to soundcard
+void modulator(uint8_t sym_in)
+{
+    liquid_float_complex sample;
+    modem_modulate(mod, sym_in, &sample);
+
+    //printf("TX ================= sample: %f + i%f\n", sample.real, sample.imag);
+
+    // interpolate by k_SampPerSymb
+    liquid_float_complex y[k_SampPerSymb];
+    firinterp_crcf_execute(TX_interpolator, sample, y);
+
+    for(unsigned int i=0; i<k_SampPerSymb; i++)
+    {
+        // move sample to 1,5kHz carrier
+        nco_crcf_step(upnco);
+        float minus_sine = -nco_crcf_sin(upnco);
+        float cosinus = nco_crcf_cos(upnco);
+        float re = y[i].real * cosinus;
+        float im = y[i].imag * minus_sine;
+        float usb = re + im;
+        // value is -1 .. +1
+
+        // adapt speed to soundcard samplerate
+        int fs;
+        while(1)
+        {
+            fs = pb_fifo_freespace(0);
+            if(fs) break;
+            usleep(10000);
+        }
+
+        pb_write_fifo(usb * 0.2); // reduce volume and send to soundcard
+    }
+}

modem/main_helper.c

@@ -37,6 +37,7 @@ int isRunning(char *prgname)
     return 0;
 }

+
 // signal handler
 void sighandler(int signum)
 {

modem/qo100modem.c

@@ -59,7 +59,6 @@ int speedmode = 4;
 int bitsPerSymbol = 2;      // QPSK=2, 8PSK=3
 int constellationSize = 4;  // QPSK=4, 8PSK=8

-
 char localIP[]={"127.0.0.1"};
 char ownfilename[]={"qo100modem"};
 char myIP[20];
@@ -68,6 +67,9 @@ int fixappIP = 0;
 int restart_modems = 0;
 int doNotLoadModems = 0;

+int caprate = 44100;
+int txinterpolfactor = 20;
+
 int main(int argc, char *argv[])
 {
 int opt = 0;
@@ -99,7 +101,7 @@ char *modemip = NULL;
         }
     }

-    if(isRunning(ownfilename) == 1)
+    if(doNotLoadModems == 0 && isRunning(ownfilename) == 1)
         exit(0);

     install_signal_handler();
@@ -107,10 +109,11 @@ char *modemip = NULL;
     init_packer();
     initFEC();
     init_fft();
+    init_audio();

     // start udp RX to listen for broadcast search message from Application
     UdpRxInit(&BC_sock_AppToModem, UdpBCport_AppToModem, &bc_rxdata, &keeprunning);
-
+
     // start udp RX for data from application
     UdpRxInit(&DATA_sock_AppToModem, UdpDataPort_AppToModem, &appdata_rxdata, &keeprunning);

@@ -169,7 +172,6 @@ SPEEDRATE sr[9] = {

 void startModem()
 {
-char stx[512];
 char srx[512];

     if(speedmode >= 0 && speedmode <=5)
@@ -183,30 +185,24 @@ char srx[512];
         constellationSize = (1<<bitsPerSymbol); // QPSK=4, 8PSK=8
     }

+    caprate = sr[speedmode].audio;
+    txinterpolfactor = sr[speedmode].tx;
+
     if(doNotLoadModems == 1) return;

     if(speedmode >= 0 && speedmode <=5)
-    {
-        sprintf(stx,"python3 qpsk_tx.py -r %d -s %d &",sr[speedmode].tx,sr[speedmode].audio);
         sprintf(srx,"python3 qpsk_rx.py -r %d -s %d &",sr[speedmode].rx,sr[speedmode].audio);
-    }
     else if(speedmode >= 6 && speedmode <=7)
-    {
-        sprintf(stx,"python3 tx_8psk.py -r %d -s %d &",sr[speedmode].tx,sr[speedmode].audio);
         sprintf(srx,"python3 rx_8psk.py -r %d -s %d &",sr[speedmode].rx,sr[speedmode].audio);
-    }
     else
     {
         printf("wrong modem number\n");
         exit(0);
     }
-
-    // the TX modem needs the local IP address as a parameter -i ip
-    if(run_console_program(stx) == -1)
-    {
-        printf("cannot start TX modem\n");
-        exit(0);
-    }
+
+    // int TX audio and modulator
+    init_dsp();
+    init_audio();

     // the RX modem needs the app's IP address as a parameter -i ip
     if(run_console_program(srx) == -1)
@@ -354,13 +350,22 @@ void appdata_rxdata(uint8_t *pdata, int len, struct sockaddr_in* rxsock)
         int r = system("sudo shutdown now");
         exit(r);
     }
-
+
     if(getSending() == 1) return;   // already sending (Array sending)

     if(minfo == 0)
     {
-        toGR_Preamble(); // first transmission of a data block, send preamble
-        toGR_sendData(pdata+2, type, minfo);
+        // this is the first frame of a larger file
+        // send it multiple times, like a preamble, to give the
+        // receiver some time for synchronisation
+        // duration: 3 seconds
+        // caprate: samples/s. This are symbols: caprate/txinterpolfactor
+        // and bits: symbols * bitsPerSymbol
+        // and bytes/second: bits/8 = (caprate/txinterpolfactor) * bitsPerSymbol / 8
+        // one frame has 258 bytes, so we need for 5s: 5* ((caprate/txinterpolfactor) * bitsPerSymbol / 8) /258 + 1 frames
+        int numframespreamble = 3* ((caprate/txinterpolfactor) * bitsPerSymbol / 8) /258 + 1;
+        for(int i=0; i<numframespreamble; i++)
+            toGR_sendData(pdata+2, type, minfo);
     }
     else if((len-2) < PAYLOADLEN)
     {
@@ -376,37 +381,15 @@ void appdata_rxdata(uint8_t *pdata, int len, struct sockaddr_in* rxsock)
     }
 }

-void toGR_Preamble()
-{
-    srand(123);
-    // send random data, rx can sync
-    uint8_t data[UDPBLOCKLEN];
-
-    // 1byte 1,8ms (about 2ms)
-    int timeforframe = 2 * UDPBLOCKLEN; // 160 ms
-    int repeats = 8000 /timeforframe;   // for 8000ms = 8s
-
-    for(int i=0; i<repeats; i++)
-    {
-        for(int j=0; j<UDPBLOCKLEN; j++)
-            data[j] = rand();
-
-        sendUDP(localIP,UdpDataPort_toGR,data,UDPBLOCKLEN);
-        usleep(300000);
-    }
-}
-
 void toGR_sendData(uint8_t *data, int type, int status)
 {
     int len = 0;
     uint8_t *txdata = Pack(data,type,status,&len);

-    //printf("senddata %d\n",len);
+    //showbytestring((char *)"BERtx: ", txdata, len);

     if(txdata != NULL)
-    {
-        sendUDP(localIP,UdpDataPort_toGR,txdata,len);
-    }
+         sendToModulator(txdata,len);
 }

 #define SPEEDMEAN 3
@@ -469,7 +452,7 @@ void measure_speed(int len)
     meansumbytes = 0;
 }

-// called by UDP RX thread for data from GR
+// called by UDP RX thread for data from GnuRadio Receiver
 void GRdata_rxdata(uint8_t *pdata, int len, struct sockaddr_in* rxsock)
 {
     // raw symbols

modem/qo100modem.h

@@ -28,6 +28,8 @@
 #include "frameformat.h"
 #include "main_helper.h"
 #include "udp.h"
+#include "bass.h"
+#include <liquid/liquid.h>

 #define jpg_tempfilename "rxdata.jpg"

@@ -45,7 +47,6 @@ int cfec_Reconstruct(uint8_t *darr, uint8_t *destination);
 uint8_t *Pack(uint8_t *payload, int type, int status, int *plen);
 void GetFEC(uint8_t *txblock, int len, uint8_t *destArray);
 void initFEC();
-void toGR_Preamble();
 void toGR_sendData(uint8_t *data, int type, int status);
 uint16_t *make_waterfall(uint8_t *pdata, int len, int *retlen);
 void init_fft();
@@ -62,12 +63,17 @@ void convertBytesToSyms_8PSK(uint8_t *bytes, uint8_t *syms, int bytenum);
 void rotate8PSKsyms(uint8_t *src, uint8_t *dst, int len);
 uint8_t * rotateBack8PSK(uint8_t *buf, int len, int rotations);
 void setSending(uint8_t onoff);
-void toGR_Preamble();
 int getSending();
 void doArraySend();
 int arraySend(uint8_t *data, int length, uint8_t type, char *filename);
 void shiftleft(uint8_t *data, int shiftnum, int len);
 void showbytestring16(char *title, uint16_t *data, int anz);
+int isTXRunning(char *prgname);
+int pb_fifo_freespace(int nolock);
+int init_audio();
+void sendToModulator(uint8_t *d, int len);
+void pb_write_fifo(float sample);
+int init_dsp();


 extern int keeprunning;
@@ -76,7 +82,8 @@ extern int speed;
 extern int speedmode;
 extern int bitsPerSymbol;
 extern int constellationSize;
-
+extern int caprate;
+extern int txinterpolfactor;

 /*
  * Constellation as produced by the GR Constellation Decoder:

modem/qpsk_rx.py

@@ -42,8 +42,8 @@ class qpsk_rx(gr.top_block):
         self.qpsk__constellation = qpsk__constellation = digital.constellation_rect([0.707+0.707j, -0.707+0.707j, -0.707-0.707j, 0.707-0.707j], [0, 1, 2, 3],
         4, 2, 2, 1, 1).base()
         self.qpsk__constellation.gen_soft_dec_lut(8)
-        self.outputsps = outputsps = 7
-        self.nfilts = nfilts = 32
+        self.outputsps = outputsps = 8
+        self.nfilts = nfilts = 15
         self.mixf = mixf = 1500

         ##################################################

modem/qpsk_tx.py

@@ -1,140 +0,0 @@
-#!/usr/bin/env python3
-# -*- coding: utf-8 -*-
-
-#
-# SPDX-License-Identifier: GPL-3.0
-#
-# GNU Radio Python Flow Graph
-# Title: QPSK TX-Modem
-# Author: DJ0ABR
-# Copyright: DJ0ABR
-# Description: requires GNU Radio 3.8xxx
-# GNU Radio version: 3.8.2.0
-
-from gnuradio import analog
-from gnuradio import audio
-from gnuradio import blocks
-from gnuradio import digital
-from gnuradio import gr
-from gnuradio.filter import firdes
-import sys
-import signal
-from argparse import ArgumentParser
-from gnuradio.eng_arg import eng_float, intx
-from gnuradio import eng_notation
-
-
-class qpsk_tx(gr.top_block):
-
-    def __init__(self, resamprate=20, samp_rate=44100):
-        gr.top_block.__init__(self, "QPSK TX-Modem ")
-
-        ##################################################
-        # Parameters
-        ##################################################
-        self.resamprate = resamprate
-        self.samp_rate = samp_rate
-
-        ##################################################
-        # Variables
-        ##################################################
-        self.qpsk__constellation = qpsk__constellation = digital.constellation_rect([1+1j, -1+1j, -1-1j, 1-1j], [0, 1, 2, 3],
-        4, 2, 2, 1, 1).base()
-        self.mixf = mixf = 1500
-
-        ##################################################
-        # Blocks
-        ##################################################
-        self.digital_constellation_modulator_0 = digital.generic_mod(
-            constellation=qpsk__constellation,
-            differential=False,
-            samples_per_symbol=resamprate,
-            pre_diff_code=True,
-            excess_bw=0.35,
-            verbose=False,
-            log=False)
-        self.blocks_udp_source_0 = blocks.udp_source(gr.sizeof_char*1, '127.0.0.1', 40134, 258, False)
-        self.blocks_multiply_xx_0_0 = blocks.multiply_vcc(1)
-        self.blocks_multiply_const_vxx_0 = blocks.multiply_const_ff(0.05)
-        self.blocks_complex_to_float_1 = blocks.complex_to_float(1)
-        self.blocks_add_xx_0 = blocks.add_vff(1)
-        self.audio_sink_0_0 = audio.sink(samp_rate, '', True)
-        self.analog_sig_source_x_0_0_0 = analog.sig_source_c(samp_rate, analog.GR_COS_WAVE, mixf, 1, 0, 0)
-
-
-
-        ##################################################
-        # Connections
-        ##################################################
-        self.connect((self.analog_sig_source_x_0_0_0, 0), (self.blocks_multiply_xx_0_0, 1))
-        self.connect((self.blocks_add_xx_0, 0), (self.blocks_multiply_const_vxx_0, 0))
-        self.connect((self.blocks_complex_to_float_1, 0), (self.blocks_add_xx_0, 0))
-        self.connect((self.blocks_complex_to_float_1, 1), (self.blocks_add_xx_0, 1))
-        self.connect((self.blocks_multiply_const_vxx_0, 0), (self.audio_sink_0_0, 0))
-        self.connect((self.blocks_multiply_xx_0_0, 0), (self.blocks_complex_to_float_1, 0))
-        self.connect((self.blocks_udp_source_0, 0), (self.digital_constellation_modulator_0, 0))
-        self.connect((self.digital_constellation_modulator_0, 0), (self.blocks_multiply_xx_0_0, 0))
-
-
-    def get_resamprate(self):
-        return self.resamprate
-
-    def set_resamprate(self, resamprate):
-        self.resamprate = resamprate
-
-    def get_samp_rate(self):
-        return self.samp_rate
-
-    def set_samp_rate(self, samp_rate):
-        self.samp_rate = samp_rate
-        self.analog_sig_source_x_0_0_0.set_sampling_freq(self.samp_rate)
-
-    def get_qpsk__constellation(self):
-        return self.qpsk__constellation
-
-    def set_qpsk__constellation(self, qpsk__constellation):
-        self.qpsk__constellation = qpsk__constellation
-
-    def get_mixf(self):
-        return self.mixf
-
-    def set_mixf(self, mixf):
-        self.mixf = mixf
-        self.analog_sig_source_x_0_0_0.set_frequency(self.mixf)
-
-
-
-
-def argument_parser():
-    description = 'requires GNU Radio 3.8xxx'
-    parser = ArgumentParser(description=description)
-    parser.add_argument(
-        "-r", "--resamprate", dest="resamprate", type=intx, default=20,
-        help="Set resamprate [default=%(default)r]")
-    parser.add_argument(
-        "-s", "--samp-rate", dest="samp_rate", type=intx, default=44100,
-        help="Set samp_rate [default=%(default)r]")
-    return parser
-
-
-def main(top_block_cls=qpsk_tx, options=None):
-    if options is None:
-        options = argument_parser().parse_args()
-    tb = top_block_cls(resamprate=options.resamprate, samp_rate=options.samp_rate)
-
-    def sig_handler(sig=None, frame=None):
-        tb.stop()
-        tb.wait()
-
-        sys.exit(0)
-
-    signal.signal(signal.SIGINT, sig_handler)
-    signal.signal(signal.SIGTERM, sig_handler)
-
-    tb.start()
-
-    tb.wait()
-
-
-if __name__ == '__main__':
-    main()

modem/tx_8psk.py

@@ -1,145 +0,0 @@
-#!/usr/bin/env python3
-# -*- coding: utf-8 -*-
-
-#
-# SPDX-License-Identifier: GPL-3.0
-#
-# GNU Radio Python Flow Graph
-# Title: 8PSK Modem  DJ0ABR
-# Author: kurt
-# Description: requires GNU Radio 3.8xxx
-# GNU Radio version: 3.8.2.0
-
-from gnuradio import analog
-from gnuradio import audio
-from gnuradio import blocks
-from gnuradio import digital
-from gnuradio import gr
-from gnuradio.filter import firdes
-import sys
-import signal
-from argparse import ArgumentParser
-from gnuradio.eng_arg import eng_float, intx
-from gnuradio import eng_notation
-
-
-class tx_8psk(gr.top_block):
-
-    def __init__(self, resamprate=24, samp_rate=48000):
-        gr.top_block.__init__(self, "8PSK Modem  DJ0ABR")
-
-        ##################################################
-        # Parameters
-        ##################################################
-        self.resamprate = resamprate
-        self.samp_rate = samp_rate
-
-        ##################################################
-        # Variables
-        ##################################################
-        self.sps = sps = 1
-        self.nfilts = nfilts = 32
-        self.mixf = mixf = 1500
-
-        ##################################################
-        # Blocks
-        ##################################################
-        self.digital_constellation_modulator_0 = digital.generic_mod(
-            constellation=digital.constellation_8psk_natural().base(),
-            differential=True,
-            samples_per_symbol=resamprate,
-            pre_diff_code=True,
-            excess_bw=0.25,
-            verbose=False,
-            log=False)
-        self.blocks_udp_source_0 = blocks.udp_source(gr.sizeof_char*1, '127.0.0.1', 40134, 258, False)
-        self.blocks_multiply_xx_0_0 = blocks.multiply_vcc(1)
-        self.blocks_multiply_const_vxx_0 = blocks.multiply_const_ff(0.05)
-        self.blocks_complex_to_float_1 = blocks.complex_to_float(1)
-        self.blocks_add_xx_0 = blocks.add_vff(1)
-        self.audio_sink_0_0 = audio.sink(samp_rate, '', True)
-        self.analog_sig_source_x_0_0_0 = analog.sig_source_c(samp_rate, analog.GR_COS_WAVE, mixf, 1, 0, 0)
-
-
-
-        ##################################################
-        # Connections
-        ##################################################
-        self.connect((self.analog_sig_source_x_0_0_0, 0), (self.blocks_multiply_xx_0_0, 1))
-        self.connect((self.blocks_add_xx_0, 0), (self.blocks_multiply_const_vxx_0, 0))
-        self.connect((self.blocks_complex_to_float_1, 0), (self.blocks_add_xx_0, 0))
-        self.connect((self.blocks_complex_to_float_1, 1), (self.blocks_add_xx_0, 1))
-        self.connect((self.blocks_multiply_const_vxx_0, 0), (self.audio_sink_0_0, 0))
-        self.connect((self.blocks_multiply_xx_0_0, 0), (self.blocks_complex_to_float_1, 0))
-        self.connect((self.blocks_udp_source_0, 0), (self.digital_constellation_modulator_0, 0))
-        self.connect((self.digital_constellation_modulator_0, 0), (self.blocks_multiply_xx_0_0, 0))
-
-
-    def get_resamprate(self):
-        return self.resamprate
-
-    def set_resamprate(self, resamprate):
-        self.resamprate = resamprate
-
-    def get_samp_rate(self):
-        return self.samp_rate
-
-    def set_samp_rate(self, samp_rate):
-        self.samp_rate = samp_rate
-        self.analog_sig_source_x_0_0_0.set_sampling_freq(self.samp_rate)
-
-    def get_sps(self):
-        return self.sps
-
-    def set_sps(self, sps):
-        self.sps = sps
-
-    def get_nfilts(self):
-        return self.nfilts
-
-    def set_nfilts(self, nfilts):
-        self.nfilts = nfilts
-
-    def get_mixf(self):
-        return self.mixf
-
-    def set_mixf(self, mixf):
-        self.mixf = mixf
-        self.analog_sig_source_x_0_0_0.set_frequency(self.mixf)
-
-
-
-
-def argument_parser():
-    description = 'requires GNU Radio 3.8xxx'
-    parser = ArgumentParser(description=description)
-    parser.add_argument(
-        "-r", "--resamprate", dest="resamprate", type=intx, default=24,
-        help="Set resamprate [default=%(default)r]")
-    parser.add_argument(
-        "-s", "--samp-rate", dest="samp_rate", type=intx, default=48000,
-        help="Set samp_rate [default=%(default)r]")
-    return parser
-
-
-def main(top_block_cls=tx_8psk, options=None):
-    if options is None:
-        options = argument_parser().parse_args()
-    tb = top_block_cls(resamprate=options.resamprate, samp_rate=options.samp_rate)
-
-    def sig_handler(sig=None, frame=None):
-        tb.stop()
-        tb.wait()
-
-        sys.exit(0)
-
-    signal.signal(signal.SIGINT, sig_handler)
-    signal.signal(signal.SIGTERM, sig_handler)
-
-    tb.start()
-
-    tb.wait()
-
-
-if __name__ == '__main__':
-    main()
